EMM low pressure two components foaming machine
EMM083 series EMM low pressure two components foaming machine is hightech model combined with international technology and after market research for polyurethane industry application. Main parts are imported and the whole equipment has reliable performance and high safety standard.
EMM083-2 ps foam food container making machine adopts one tank for POLY.,one tank for ISO., Two metering units control outflow of metering pumps.
Two metering units control pumps outflow respectively through adjusting the speed of motors, and density
is adjusted by mixing ratio.
2.1 Model: EMM083-2 EMM low pressure two components foaming machine
2.2 Foam type:hard foaming,half-hard foaming
2.3 Viscosity: (22°C)
POLY:~2000mPas
ISO:~1000mPas
2.4 Pouring output: 50-200 g/s (1:1), adjust range of mix ratio:5:1~1:1
2.5 Injection time:0.01~9.99 (accuracy reach 0.01s)
2.6 Injection Program No.:
Hand-injection: 10
Auto-injection:60
EMM083-2 EMM low pressure two components foaming machine
Component material |
POLY |
ISO. |
Quantity |
1 |
1 |
Metering Pump model |
NB3-C40F(40cc/r) |
NB3-C40F(40cc/r) |
Motor power(kw) |
5.5 |
5.5 |
Motor speed(rpm) |
500-1450 |
500-1450 |
|
DOP |
DOP |
