Specifications
Mini oil filled radiator with double heating plate REC0161 CE certification
2 OEM sevice
3 Energy saving
4 compact
Mini oil filled radiator with double heating plate REC016
Specifications(heater)
1.Temperature limiting
2.wide voltage range
3.Dynamic heating up
4.Energy saving
pact
Introduction (heater)
Small heaters designed to prevent condensation and ensure a minimum operating temperature in small enclosures
Technical Data:
Operating voltage |
120-240V AC/DC* (min. 110V, max. 265V) |
Heating element |
PTC resistor, temperature limiting |
Heater body |
aluminium, anodised |
Mounting |
screw fixing |
Fitting position |
variable |
Operating/Storage temperature |
-45 to +70 °C (-49 to +158 °F) |
Operating/Storage humidity |
max. 90 % RH (non-condensing) |
Protection type/Protection class |
IP54 / II (double insulated) |
Approvals |
VDE + UL File No. E150057 |
Note |
other voltages on request |
Operating with voltages below 140V AC/DC reduces heating performance by approx.
10%
Art. No. |
Heating capacity* |
Inrush current max. |
Pre-fuse T (time-delay) |
Surface temperature (approx.) |
Connection |
Weight (approx.) |
01622.0-00 |
5W |
2.0A |
1A |
165°C |
2 x AWG 22 sheathed cable (silicone) |
20g |
01623.0-00 |
9W |
2.5A |
2A |
175°C |
2 x AWG 22 sheathed cable (silicone) |
20g |
The Drawing:
Product details
About us
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design, production and sales of electric equipments.
