Specifications
2014 Hot Sale 950W Compact High-performance Industric Electric Fan Heater CS 1301. CE
2. OEM service
3. 2 years warrant
SAIP MEANING:
A global quality electric organization
In order to obtain the highest quality all of
Products according to international IEC normative.
SAIP VISION:
To be an enterprise lasting 103 years and beyond
To be an enterprise with a network of 20000 sales personnel and 2000 design engineers
To be the choice brand manager of major worldwide electrical brands
SAIP MISSION: To create products that deliver happiness to everyone
SAIP BUSINESS PRINCIPLE: To conduct business in a simple straightforward manner.
SAIP WORKING PRINCIPLE: To work and live happily
2014 Hot Sale 950W Compact High-performance Industric Electric Fan Heater CS 130
Product Features:
1. Compact design
2. Double insulated
3. High heating performance
4. Integrated thermostat (optional)
5. Optional clip or screw fixing
6. The compact high performance fan heater prevents formation of condensation and provides an evenly distributed interior air temperature in enclosures with electric / electronic components. The plastic enclosure provides double insulation and acts as protection against contact. The fan heater is available with integrated thermostat for temperature control. The CS 130 was designed as a stationary unit for the bottom of the enclosure. For wall fixing the fan heater CS 030 is recommended .
Technical Data:
| Heater elememnt | PTC resistor, self regulating and temperature limiting |
| Temperature safety cut-out | to protect against overheating in case of fan failure |
| Axial fan, ball baring | air flow see table |
| service life 50,000h at 25°C(77°F) | |
| Connection | 2-pole max. 2.5mm², clamping screw with strain relief, |
| Casing | plastic according to UL94 V-0, black |
| Mounting | clip for 35mm DIN rail, EN 60715 |
| Fitting position | horizontal |
| Dimensions | 100x128x165mm |
| Weight | approx. 1.25kg |
| Operating/storage temperature | -45 to +70°C (-49 to +158°F) |
| Protection type/Production class | IP20 / II (double insulated) |
| Art. No. | Model | Operating voltage | Heating capacity | Inrush current max. | Setting range |
| 13060.0-00 | Fan heater with thermostat | 230VAC, 50/60Hz | 1200W | 13A | 0 to +60°C |
| 13060.0-01 | Fan heater without thermostat | 230VAC, 50/60Hz | 1200W | 13A | - |
| 13060.9-00 | Fan heater with thermostat | 120VAC, 50/60Hz | 1200W | 16A | +32 to +140°F |
| 13060.9-01 | Fan heater without thermostat | 120VAC, 50/60Hz | 1200W | 16A | - |
* at 20°C (68°C) ambient temperature
Product Pictures:
About Our Saip:
Saip Electric Group Co., Ltd (called "Saip" for short) is an enterprise specialized in design, production and sales of electric equipments.
Head office located in the largest manufacturing base of electric equipment of Wenzhou China, which is called "the Electric Equiment Capital of China".
We have 5 specialized branches,over 300 specialized cooperative partners.
Saip,an ISO9001 certificated enterprise.
With 20 years of development history, Zhejiang Saip Electric Co., Ltd. has become a modern enterprise integrating the production,sale with research.
