Specifications
ISO9001:2000ISO14001:2004
CCC,PCCC,RoHS
Xlpe Cable,nuclear grade cable
Mineral insulated cables, power cable
1. 0.6/1kV XLPE INSULATED POWER CABLE
XLPE insulated power cable has a number of advantages over paper insulated and PVC insulated cable.XLPE power cable has high electric strength,mechanical strength,high-ageing resisting,environmetal stress resisting antichemical corrossion,and it is simple construction,using convenient and higher operating of long term temperature.It can be laid with no drop restriction.
Various of flame-retardant and non-flame retardant XLPE cable can be manufactured with three technology(peroxide, silane and irradiation crosslinking). The flame-retardant cable covers all kinds of low-smoke low-halogen low-smoke halogen free,and non-smoke nonhalogented and three classes of A,B,C.
Our XLPE power cable can be manufactured according to companys specification which is equivalent to IEC 60502,IEC 60332,and IEC 60754.Some of indexes are superior to above international standard IEC.
Some of special XLPE power cable can be manufactured according to the other standards required by customs.
XLPE power cable having higher long-term working temperature and greater current rating,at the same environment XLPE cable may be reduced size(nominal cross-section)1or 2 class in comparison with paper and PVC cable.This is not only improve the quality and properties of products,but also reduce cables production costs.
2.Scope of XLPE Power Cable
Type |
No. of Cores |
Nominal Cross-Section of Conductor(mm2) |
|
YJV YJLV YJV YJLV YJV22 YJLV22 YJV23 YJLV23 YJV32 YJLV32 YJV33 YJLV33 YJV42 YJLV42 YJV43 YJLV43 ZR-YJV ZR-YJLV ZR-YJY ZR-YJLY ZR-YJV22 ZR-YJLV22 ZR-YJV23 ZR-YJLV23 ZR-YJV32 ZR-YJLV32 ZR-YJV33 ZR-YJLV33 ZR-YJV42 ZR-YJLV42 ZR-YJV43 ZR-YJLV43 |
1 |
1.5--1000 |
|
2 3 4 5 |
1.5--400 |
|
|
3+1 4+1 3+2 |
2.5--400 |
ZR- covers three classes A,B,C of flame-retardant cable.It can be expressed as ZRA-,or ZRB-or ZRC-separately.For example:ZRB-YJV,or ZRA-YJV22.
