Gable Top Carton Filling Machine for beverage 003

Specifications

we are special for gable top carton filling machine (liquid filling).









This type of machine suits to fill liquids like juice, fruit vinegar beverage, yogurt, milk beverage, corn beverage, tea beverage, etc. All of the liquid mentioned above can be filled in hot temperature (85-92°C) and kept in normal temperature with shelf period in 3 months to 12 months according to different products. This machine can be designed differently according to the different requests by different customers.



Process Flow







Purchased Carton→ Bottom Preformed → Bottom Molding→ Filling → Top Preformed → Top Molding→ Seal → Print date → Gable Top Carton Products







There is only one person needed, and the whole process is controlled by PLC.







Technical Parameter



1



,Packing capacity:200ml to 2000ml,which can be filled in the same machine
2,Production quantity:1500 to 2000 Boxes/hour(by 500ml)
3,Box material: carton with aluminum-foil bottom size 95mm*95mm, 70mm*70mm, 57mm*57mm (only one to choose)
4,Cap:Without cap
5,Filling temperature:5-50°C
6,Power rate for whole set:16KW
8,Compressed air: Pressure:1.0-1.4Mpa, Flow rate:1.4-2M3/min,without oil, water & dust
9,Cooling water:Flow volume:≥40L/ min    Temperature:≤15°C
10,Aspect Size:(Length*Width*Height)3.7*1.6*2.8m
11,Machine weight:3000KG
12,Installation Requirement:Cement, floor tile, plastic ground, any one is OK. Do not need to make angle.







Fruit and vegetable juice production line for gable top carton



1. process flow:







2. machine technics









3. Applied products:



various fruit and vegetable juice beverage, fruit vinegar beverage, yoghurt, cereal and corn juice beverage, such products via hot filling.



4. Product character:



beautiful appearance, high grade, easy drinking, package material environmental protection. Suitable for supermarket, catering and hotel sales.
