Home > Lights & Lighting > LED Lighting Decoration > LED Strip Light > Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration

Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration

Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration thumbnail-1
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration thumbnail-2
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration thumbnail-3
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration thumbnail-4
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration photo-1
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration photo-2
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration photo-3
Ws2812 144leds/pcs Waterproof Led Strip Rgb5050 for Shop Decoration photo-4
US$ 1 - 9.9 MOQ: 1 Roll
Key Specifications
Get Latest Price
LED Light Source:
Epistar 5050 RGB LED chip
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Contact Supplier Request Quote Chat Now
Shenzhen IPixel LED Light Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Yantian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar 5050 RGB LED chip
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 34.56
Lamp Luminous Flux(lm) R:57600 G:100800 B:28800
Color Temperature(CCT) addressable
Working Temperature(℃) -10, +40
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name iPixel LED
Model Number S1442812B

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

Addressable full color led strips(ws2812b) ——WS2811 IC built-in 5050

RGB LED chip.

Individually control —— 1IC & ILED chip.

Standard Reel Lengt: 5meter/roll, also can be customized.

Cutted: 1 integrated RGB LEDs per segment, can be cutted per 1LED.

Sticky: with 3M adhesive on back side for sticky.

               screw+silicon clip, or 3M adhesive back side.

Type: waterproof--white PCB; non-waterproof--black PCB;

             waterproof--black PCB; non-waterproof--black PCB

Brand: iPxel LED

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

LED Chip SMD5050 RGB LED chip
IC Chip  WS2812B(WS2811 IC built-in 5050 RGB LED chip)
LED Quantity 144LEDs/m
Input Voltage DC5V
Watts 34.56W/M
IP Rate IP20(non-waterproof), IP65(Silicon-tube waterproof)
PCB Color White PCB, Black PCB
View Angle 120°
Standard Reel Length 1meter/roll, also can be customized
PCB Width 12mm
Operating Temperature -20 ~ +40°C
Storage Temperature -40 ~ +80°C
Color Addressable full color

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812b 144leds/m —— white PCB, silicon tube waterproof

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812b 144leds/m —— black PCB, non-waterproof

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812b 144leds/m —— white PCB, non-waterproof

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

Showing pictures:

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration



The compared of WS2812b 30leds/m, 60leds/m, 144leds/m:

TYPE 30LEDs/m 60LEDs/m 144LEDs/m
IC WS2812B WS2812B WS2812B
PCB Width 10mm 10mm 12mm
Standard Length 5meter/roll 5meter/roll 1meter/roll
PCB color white/black white/back white/black
Voltage DC5V DC5V DC5V
Watts 7.2W/M 14.4W/M 34.56W/M
Cutted per 1 LED per 1 LED per 1 LED

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration



Connection way: 144 ws2812b

SPI signal: LED Strips+LED power supply +LED controller

DMX control: LED Strips+LED pwer supply+DMX Controller+DMX decoder

LED controller: T- series SD card controller, RF remote controller, DMX controller, Arduino...

(offline / PC online)

LED power suppply: Meanwell power supply, T- series, A- series power supply...

(waterproof / non-waterproof)

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration

ws2812 144leds/pcs waterproof led strip rgb5050 for shop decoration
