60leds/m 5050 smd ws2812b flexible rgb led strip
Addressable full color led strips(ws2812b) ——WS2811 IC built-in 5050 RGB LED chip.
Individually control —— 1IC & ILED chip.
Standard Reel Lengt: 5meter/roll, also can be customized.
Cutted: 1 integrated RGB LEDs per segment, can be cutted per 1LED.
Sticky: with 3M adhesive on back side for sticky.
screw+silicon clip, or 3M adhesive back side.
Type: waterproof--white pcb ; non-waterproof--white pcb;
waterproof--black pcb ; non-waterproof--black pcb
Brand: iPxel LED
| LED Chip | SMD5050 RGB LED chip |
| IC Chip | WS2812B(WS2811 IC built-in 5050 RGB LED chip) |
| LED Quantity | 60LEDs/m |
| Input Voltage | DC5V |
| Watts | 14.4W/M |
| IP Rate | IP20(non-waterproof), IP65(Silicon-tube waterproof) |
| PCB Color | White PCB, Black PCB |
| View Angle | 120° |
| Standard Reel Length | 5meter/roll, also can be customized |
| PCB Width | 10mm |
| Operating Temperature | -20 ~ +40°C |
| Storage Temperature | -40 ~ +80°C |
| Color | Addressable full color |
programmable 60 LEDs/m ws2811 led digital strip ws2812b
ws2812b 60leds/m —— white PCB, non-waterproof
ws2812b 60leds/m —— black PCB, silicon-tube waterproof
ws2812b 60leds/m —— white PCB, silicon tube waterproof
Showing pictures:
The compared of WS2812b 30leds/m, 60leds/m, 144leds/m:
| TYPE | 30LEDs/m | 60LEDs/m | 144LEDs/m |
| IC | WS2812B | WS2812B | WS2812B |
| PCB Width | 10mm | 10mm | 12mm |
| Standard Length | 5meter/roll | 5meter/roll | 1meter/roll |
| PCB color | white/black | white/back | white/black |
| Voltage | DC5V | DC5V | DC5V |
| Watts | 7.2W/M | 14.4W/M | 34.56W/M |
| Cutted | per 1 LED | per 1 LED | per 1 LED |
programmable 60 LEDs/m ws2811 led digital strip ws2812b
SPI signal: LED Strip+LED power supply +LED controller
DMX control: LED Strip+LED pwer supply+DMX Controller+DMX decoder
LED controller: T- series SD card controller, RF remote controller, DMX controller, Arduino...
(offline / PC online)
LED power suppply: Meanwell power supply, T- series, A- series power supply...
(waterproof / non-waterproof)
Packing:
Usually 5meter/roll, 1roll/bag
waterproof: 60rolls/carton, 17.5KG/Carton
non-waterproof: 90rolls/carton, 12.4KG/Carton(Volume Weight)
Carton Size: 46cmx27cmx46cm
Trade Terms:
1. Payment Terms:
T/T, Western Union, Ali Excrow(Credit Card, Debit Card, Bank Transfer)
2. Lead Time:
Usually we had materials in stock, regular order delivery time 1--7days after the order(PI) paid,
Customized products 8--15days(Custom PCB).
3.Warranty:
2 years warranty since the data of purchase our LED products.
4. Delivery Ways:
DHL, Fedex, TNT UPS, EMS door to door service, by sea, by air, etc.
