T-300K System features

A. 32—256 grade Gray level, Support software Gamma correction
B. Support the rules and special-shaped handle.
C. 8 ports output, one port can support 512-1024 lamp pixels.
D. On-line (also can SD Card) control, offline control Can be multiple controllers used in combination,the

contents of the line control program stored in the SD card.
E. Compatible with single line or double line chips.
F. If the controller to the lamps distance can choose photoelectric isolated transmission and as far as several distances of up to 200-300 M

Note : the T-300 K controller offline control, each machine controller must put a SD card.
2012 Edition T-300K controller can only be combined with the new version software LedEdit2012 . Using the old software does not support the new version of the controller, the new version of the controller has been printed the Chinese sign.

Supported chips:

NOTE:  if chip is 256 grade gray level and Single-line IC choose .When programming choice high speed
mode and one interface controls 1024 lamps the play speed can reach 30 frames/s. Double-line IC or

single-line IC with low speed , one interface controls 512 lamps the play speed can reach 30 frames/s.

System architecture diagram

Memory card :
Type : SD card(if controlling so many lamps it is best to use the high-speed SD card.)
Capacity: 128MB—2GB
Format: FAT
Store file: *.led

Physical parameters :
Working temperature : -30℃—85℃
Weight: 1.35KG
Working voltage: AC220V
Working power: 8W
Size: L270mm×W180mm×H55mm
Signal port: 3pin connect port
NOTE: T-300K Support online download the effect-file to SD card.
Before copy files to SD card , The SD card must be formatted as FAT format.

Picture:

We also have other types of T- series SD card controller

T1000S

T4000C

T8000A

T200K
