Aluminum Curtain Wall Machinery 3 Axis CNC Vertical Machining Center
Machine Description
1.High quality, Fair Price, Fast Delivery.
2.OEM Service, Trail Order
3.The Color, The logo, The package according to your request,
4.We are the Manufacturer,We have many engineers for the solutions for the new market to keep the trend of the world.
Brief Product Introduction
| Name | Aluminum Curtain Wall Machinery CNC 3 Axis Machine Center |
| Model | LX3-CNC-7000 |
| Brand | SOLTERRA |
| Certificates | ISO9001:2008,SGS |
| Warranty | The Warranty time is one year,Engineers available to the service |
| Delivery time | 20 days after receiving the down payments |
| Packages | High quality Wooden case |
| Payment terms | T/T,L/C,Western Union |
1. This machine is designed for processing water slot, taping, milling, mounting hole, locking hole and other slots for diversified curtain walls, aluminum doors and windows
2. It adopts high-speed electric axis, which is imported from Italy. It is extremely efficient and can swing in ±90°
3. It adopts high-quality industrial computer control system, the system has favorable user manipulate interface program in graghics mode and processing interface. This processing interface can show related dates directly
4. It adopts high-quality servo-motor, roller linear guide pair to ensure high precision
5. The cutter storage supply 6 cutter position, the cutter can change quickly and automatically
6. With half-close safeguard device to ensure the personal safely of the operate
7. The position of clamping device can be located freely
Technical Parameter
| X-way range | 7000mm |
| Y-way range | 1400mm |
| Z-way range | 600mm |
| X-way speed | 0-60m/min |
| Y-way speed | 0-30m/min |
| Z-way speed | 0-20m/min |
| main shaft rev./power | 0-18000rpm/5.5kw |
| Cutter Magazine | 6 cutter positions,cutter auto change is avalible in the program |
| cutter max length | 165mm |
| saw blade diameter | Φ 80mm~ Φ 150mm |
| Air pressure | 0.5-0.8mpa |
| Power Supply | 380V/50HZ |
| Total Power | 10kw |
| clamp | 6 |
| Lubricating&cooling | Auto Lubricating&spray cooling |
| Work Area(W*H*L) | 650mm*200mm*7000mm |
| Overall Dimension(W*H*L) | 11300mm*2350mm*2550mm |
| Weight | 4500kg |
Machine Images
Company Profile
Established in 1991, Jinan Liaoyuan Machine Co.,Ltd is one of the most earliest enterprises in equipment machining industry. After more than 20 years unremitting efforts, now we has developed into a modern large comprehensive high-tech enterprise with four main businesses, covering industrial equipment manufacturing, aluminum casting and machining, no-ferrous metal casting, window-door & curtain wall processing machinery, and integrating with scientific research, manufacturing, sales and international trade.
Annual Exhibition
Contact Information
Question 1. Are you a Manufacturer or a trading company?
Answer 1. We are not a trading company,We are the top Machine Manufacturer,Which involves Raw materail casting,Machine body processing,Machine assembling,Painting,Machine quality Inspecting and etc.
Q 2. What is the minimum quantity for order ?
A2: Normaly One Set. and We will give some discounts if you can buy one complete set of Machine.
Q3. Do you have stock product ready to deliver?
A 3. We have many machines in stock, So We can guarantee the fast delivery time and make sure you can check the machine on LIVE-DEMONSTRATION at any time.
Q4. How do you deliver the finished products?
A 4, For FCL, We delivered by Sea
For LCL, We delivered by Sea and by Plane for only urgent requirement
For Spare Parts,We delivered by Courier,TNT, FEDEX,DHL,UPS,EMS, and Etc.
Q5,How can you guarantee the after-sales service?
A 5, We have a first-class engineers for the machine installation, tranining, and after-sales, we also have branch office in ovesea to keep the good after-sales service,They have a professional work team with exquisite experience.
Q6, What's delivery time for the machines.
A 6, We will arrange the shipment within 6 days after receiving the payment.
Q7, Do you inspect the finished products?
A7, Yes, Each step of production products will be camed out inspection by QC department before shipping.
