Aluminum Windows Automatic V Notching Cutting Saw Machine LJK-500
This Machine is popular for processing aluminum window and curtain walls
1.Automatic V notching saw for aluminum windows
2.V Notching Machine for Aluminum curtain walls
3.High quality, Fair Price, Fast Delivery.
4.OEM Service, Trail Order
5.The Color, The logo, The package according to your request,
6.We are the Manufacturer,We have many engineers for the solutions for the new market to keep the trend of the world.
| Name | Aluminum Windows Machinery V Notching Cutting Saw Machine LJK-500 |
| Model | LJK-500 |
| Brand | SOLTERRA |
| Certificates | ISO9001,SGS |
| Warranty | The Warranty time is one year, Engineers available to the service |
| Delivery time | Within 20 working days after receiving the advanced payment |
| Package | High Quality Standard Wooden case |
| Payment terms | T/T,L/C,Western Union |
As a Manufaturer, We are looking forward to finding the agents of our products all over the world!!
Equipment Features:
1. This is the new machine designed for the aluminum curtain-wall and lighting skylight processing with the special angle at the profile end surface
2. Equipped with magnetic ruler control system, realized cutting angle and worktable height digital display
3. Convenient worktable and locating device adjustment, can achieve special end surface angle processing
4. The blade saw can swing between -45°--+45°
Technical parameter:
Power supply |
380V/50Hz |
Cutting motor power |
2×2.2KW |
Motor rotary speed |
2800r/min |
Air pressure |
0.5-0.8Mpa |
Air consumption |
60L/min |
Saw blade swing range |
-45º-- +45º |
Cutting depth |
150mm |
Cutting feeding speed stepless speed regulation |
0-3m/min |
Overall dimension |
3140mm×1380mm×1800mm |
Saw blade specification |
Φ500mm×4.4mm×Φ30mm Z=120 |
Weight |
1500kg |
Machine Images
Liaoyuan Machine established in the 1990s. Liaoyuan Machine is located in Jinan city of China, originally started to make pvc/aluminum window & door machine from 1991 year. We are the only one chinese company who enjoy the capacity from spare parts casting, machine design, technology innovation and machine assembling, which are totally achieved at your factory.
In more than 20 years of development, Liaoyuan Machine has energetically explored the resource development space to realize rapid development. Nowadays, Liaoyuan Machine has been developed into a large machine tool production enterprise with a land area of four hectares, a workshop area of 15,000 square meters, more than 350 employees, more than 100 sets of professional production equipment and annual designing and production ability of more than 700 sets of machine tools. In 1998, Liaoyuan Machine was granted the authorized import & export license by the Commission of Foreign Trade and Economic Cooperation of China.
Jinan Liaoyuan Machine Co.,Ltd Attend the Annual Machinery Exhibition
With Fully ISO9001 Approved, For more information about the certificate,please
feel free to contact me!!
Contact Information:
Question 1. Are you a Manufacturer or a trading company?
Answer 1. We are not a trading company,We are the top Machine Manufacturer,Which involves Raw materail casting,Machine body processing,Machine assembling,Painting,Machine quality Inspecting and etc.
Q 2. What is the minimum quantity for order ?
A2: Normaly One Set. and We will give some discounts if you can buy one complete set of Machine.
Q3. Do you have stock product ready to deliver?
A 3. We have many machines in stock, So We can guarantee the fast delivery time and make sure you can check the machine on LIVE-DEMONSTRATION at any time.
Q4. How do you deliver the finished products?
A 4, For FCL, We delivered by Sea
For LCL, We delivered by Sea and by Plane for only urgent requirement
For Spare Parts,We delivered by Courier,TNT, FEDEX,DHL,UPS,EMS, and Etc.
Q5,How can you guarantee the after-sales service?
A 5, We have a first-class engineers for the machine installation, tranining, and after-sales, we also have branch office in ovesea to keep the good after-sales service,They have a professional work team with exquisite experience.
Q6, What's delivery time for the machines.
A 6, We will arrange the shipment within 15 days after receiving the payment.
Q7, Do you inspect the finished products?
A7, Yes, Each step of production products will be camed out inspection by QC department before shipping
