ncrete block making machine price
2.block making machine
3.eps block machine
4.beton blocks machines
ISO9001:2000
1.Main technical Specifications:
1,its face mix device is able to produce pavers with color layer. |
2,Compact design semi-automatic control result in easy operation. Low investment brings you cost-saving |
3,Our machines , with harmonic cooperation with mechanical, electrical and hydraulic machines functions, guarantees a reliable and high output of concrete products |
Raw materials :crushed stone ,sand, cement, etc; many type of industrial waste, like, lime, fly ash, slag, coal gangue, gravel, perlite , ect. .
multiple uses, it can produce all type of standar d building blocks by changing mould.
1,Multi-holes block and hollow block .
2,Ceram site heat preservation block.
3,Composite heat preservation concrete block
The above production come with good heat preservation performance, and it meets the new national energy conservation policy./
2.Main technical parameters
Cycle Time | 20-30s/ time | Capacity/8 hours | Paving block 150-200square Hollow block 2400-3000pcs |
Vibration frequency | 4500-5100 Times/sub | Oil pump motor | Y132S2-4 N=5.5kw |
Jack cylinder | 80X300 Φ50 | Side cylinder | 63X250 Φ40 |
Rated pressure of hydraulic system | 8.5Mpa | Total Power | 21.4kw |
Pallet Size | 680 x 535 x 20mm | Gross Weight | About 3000kg |
Machine Dimension | 4000 x 3500 x 2300mm | Load capacity | Standard block 21pcs, Hollow block 3pcs |
3.Product shows:
4.Block and brick Samples:
