Specifications
QT8-15 hollow block machine1.capacity:11520-15360pcs/shift
2.power:38.1kw
3.rated pressured:31.5mpa
4.force:95kn
QT8-15 hollow block machine
1.capacity:11520-15360pcs/shift
2.power:38.1kw
3.rated pressured:31.5mpa
4.force:95kn
Big Professional Brick & block making machine Manufacturer
FuJian HuaYuan Machinery Co.,Ltd
Address: Quanzhou city, Fujian Province, China
MP:86-152 6078 7045 Banson Huang
Skype:allence220
Introduction of full automatic hollow block machine :
1.Super-strong steel structure,made of extensive imported original parts,ensuring more stability and reliability for the main machine body.
2.The whole process uses a PLC aptitude control and dialogue system of human -machine interface,easy to analyze the chance signal,ensure the best operation effect.
3.High-efficiency and super-strong vibration system, computer control flow pressure of the hydraulic system,realize vertically thus greatly increase products compactness and mold-box service life.
4.The cloth system adopts semi-closed screen reticular feeding unit to feed materials forcedly, with evenness and even speed , ensuring product intensity.
5.Fitted with special hydraulic loading unit,readily realize mass and automatic production,saving a greatdeal of human power,maintenance, and circulating fund investment.
A: Production capacity of QT8-15 full automatic hollow block machine as following:
Brick |
Sizes |
Output/ mould |
Output/Shift(8hours) |
picture |
Blocks |
390x190x190mm |
8 |
11,520-15,360 |
|
Porous bricks |
240x115x90mm |
18 |
29,800-39,450 |
|
Interlocking block |
200x100x60mm |
28 |
40,320-53,760 |
|
Solid bricks |
240x115x53mm |
40 |
57,600-76,800 |
|
B.Technical parameters of QT8-15 full automatic hollow block machine :
| Main machine size | 9800*3600*2800mm | Pallet size | 900x840x25mm |
| Total power | 38.1KW | Weight | 10500 KG |
| Rated pressure | 31.5 Mpa | Mixer | JS750 |
| Vibration force | 95KN | Belt conveyor | 8m |
| Forming cycle | 15-20 Second | Voltage | 380V,3 phase |
C.QT8-15 full automatic hollow block machine other information:
1. Ground: workshop area:1700--2400 Square foot,all factory area:58000--72000 Square foot;
2.Worker: seven to ten
3.Ratio of raw material:
Cement 8%--10%,Sand 30%--40%,Stone 50%--60%. about cement:sand:stone is 1:4:5
4.hollow block weight:
390x190x190: 17.5KG 190x140x190: 14 KG
390x90x190: 11KG
5.Raw Material Conumption per day: 112T--130T
6.Water consumption per day: In accordance with the amount by raw material's moisture decreases or add.
D. QT8-15 full automatic hollow block machine guarantee:
Our hollow block making machine is of one year guarantee,during the period we could supply spare parts is they are broken.
E. QT8-15 full automatic hollow block machine production pressure:
Hollow blocks can reach 10--30Mpa,Solid bricks can reach 30-50 Mpa.So they have ahigh pressure,can be used widely.
F.QT8-15 full automatic hollow block machine guarrantee:
We give our automatic cement brick making machineone year guarantee,
during the period we can supply spares if they are broken.
G.Advantages of QTY8-15 full automatic hollow block machine :
a:Hydraulic from Taiwan, Hydraulic valve from Japan ,well-known brand,the quality is very good.
b:the PLC is Siemens,touch screen.
c:the steel is our best national standard No.45 steel.
d:the welding is the best welding technology in our country,anti-wear, aseismatic,anti Moist
e:the mould is high temperature carburizing heat treatment through 900 Degrees Celsius
H.Workshop and Products Shows:
I. QT8-15 hollow block machine `s mould:
J, Our world customers:
K.Pls don`t hesitate to contact me as following:
