Home > Products > Ultrasonic Transducer > Ultrasonic Flow Meter Price125KHz Ultrasonic TransducerUltrasonic Transducer in Air for Flow MeterUltrasonic Air Flow Sensor
Ultrasonic Flow Meter Price125KHz Ultrasonic TransducerUltrasonic Transducer in Air for Flow MeterUltrasonic Air Flow Sensor
US$ 16.26 - 23.58
/ Piece
100 Pieces(Min. Order)
- shenzhen
- Credit Card
You May Like
-
1.0MHz Ultrasonic Flow Sensor for Water Flow MeterSensorsHigh Frequency 1MHz Water Flow MeterUltrasonic Water Flow Meter Sensor
-
High Quality Ultrasonic SensorPiezo Ultrasonic Transducer30KHz Long Range(0.6m - 20m) Ultrasonic Sensor for Distance Measurement
-
1.20MHz Small Ultrasonic Transducer for Flow Rate MeasurementSmall Ultrasonic Flow Copper TransducerSensorsUltrasonic Transducer
-
22KHz Piezo Ultrasonic Transducer for Distance MeasurementSensorsLong Range(0.6-30m)Ultrasonic Sensor for Distance Measurement
-
SensorsUltrasonic Bobble SensorUltrasonic Air-in-line Detector2.5MHz Ultrasonic TransducerUltrasonic Air Bubble Detection Sensor
-
Air Bubble DetectorUltrasonic Bubble DetectorUltrasonic Gas Bubble DetectorSensors2.5MHz Ultrasonic Transducer for Bubble Detect
Product Details
| Place of Origin | Guangdong, China | Brand Name | DYP | |
| Model Number | DYP-UL014 | Usage | Position Sensor | |
| Theory | Ultrasonic Sensor | Output | Digital Sensor |
Product Description
Specifications
This ultrasonic transducer is used for distance measurement in air,the detection distance is 0.20 m - 3.0 m.This ultrasonic transducer is used for distance measurement in air,the detection distance is 0.20 m - 3.0 m and is widely used in location, flow measurement, approach measurement,traffic measurement, escaped obstruction,robot and etc.
Structure diagram:
Technical parameters:
Center resonant frequency (kHz) | 125KHZ |
Bandwidth | ±4% |
Detection distance | 0.20 m—3.0 m |
Blind zone | <0.20 m |
Launch angle beam (-3dB full angle) | 14±2° |
Electrostatic capacitance | 1000PF±200PF |
Minimum parallel impedance | 300Ω±30% |
Maximum working voltage (Pulse wave - 2% duty cycle) | <800V |
Operating temperature | -20~80°C |
Protection class | IP65 |
Housing material | ABS |
Size (diameter * height, mm) | Φ25 X 25 |
Cable length | 2 m |
Weight | 20kg |
