H Beam Steel Automatic Welding Production Line Integral (3 in 1)making Machine

FOB Price

US$ 30,000 - 40,000 / Piece

1 Piece(Min. Order)

Port SHANGHAI
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	YQ(YaoQiang)
Model Number	YQPJ1000 / YQPJ1200 / YQPJ1500		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

H beam Assembly Welding Straightening Machine

Brief Description:

1.The main assembly unit adopts the heavy duty assembly machine patent which has been submitted for approval.The web and flange are positioned automatically,with highly improved accuracy and

efficiency;

2.The endurable welding guns fix device can adjust height as well as horizontal move place.It can also adjust the welding guns angle from 2 position.So the welding seam can be nice and neat;

3.Assisting straightening part have unique design.The two straightening wheels could actively straight en the work piece under cylinder drive.From the straightening device,the user can see clearly the welding seam,easy for welding gun position adjustment and observation of welding seam;

4.The main assembly unit together with assistant straightening unit could be used as assembly- weld machine or assembly machine separately;

5.After modification,the straightening unit could be used as mini straightening machine.

H beam 3 in 1 Machine Main technical parameters:

Model	web height	web thickness	welding and straightening speed	flange width	flange thickness	overall power
YQPJ1000	1000mm	6-16mm	0.35-3m/min	200-800mm	6-20mm	13.4kw
YQPJ1200	1200mm	6-16mm	0.35-3m/min	200-800mm	6-20mm	13.4kw
YQPJ1500	1500mm	6-16mm	0.35-3m/min	200-800mm	6-20mm	13.4kw

Work piece flange width / thickness	200-800mm / 6-20mm
Work piece web highness / thickness	350-1500mm / 6-16mm
Main drive roll diameter	Φ250mm
Main drive roll speed	350-6000mm/min
Main drive roll speed adjust	AC frequency no rate speed adjustment
Straightening wheel diameter	Φ180mm
Straightening hydro-cylinder lift length	200mm
Straightening hold wheel diameter	Φ380mm
Main drive roll engine power	7.5KW
Upper roller wheel diameter	Φ160mm
Upper roller lift hydro-cylinder distance	1350mm

H beam Assembly-Weld-Straighten Machine Images Show:

Our Service--We Cherish Every Order From Every Customer

Punctual delivery time:

•We put your order into our tight production schedule, ensure your punctual delivery time.

•Production / inspection report before your order packed.

•Shipping notice/ insurance to you as soon as your order is shipped.

Pre-sales service:

•We value every inquiry sent to us, ensure quick competitive offer within 12 hours.

•We cooperate with customer to design and develop the new products. Provide all necessary document.

•We are a sales team, with all technical support from engineer team.

After sales service:

•We respect your feed back after receive the goods.

•We provide 12-24 months warranty after goods arrive.

•We promise all spare parts available in lifetime use.

•We lorge your complain within 48 hours.

Trade Assurance:

Packaging & Delivery:

Packaging Details: Standard export package

Delivery Details: Within 15 days after received deposit

Company Show:

Company Honor:

Transaction Process:

Sales Network:

FAQ:

1. Are you factory or foreign trade company?

We have our own factory, We are industry and trade integration.

2. Where is your factory located? How can I visit there?

Our factory is located in Dongtai City, Jiangsu Province, one hour train from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!

3. What's the quality of your products?

We are very focused on the quality of the products, good quality products can bring us more customers, so, All spare parts of this machine come with best brand and best quality, after completing the installation we will test the machine for 48 hours, also we can provide the machine's working video before shipping.

4. What shall we do if don't know how to operate your machine after bought from you?

We have detailed installation and operating instructions attached, also comes with video, it is very simple. We have telephone and email support at 24 hours a day.

5. What to do if the machine has a problem?

24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.

6. What other things also need after we bought your machines?

(1) With flame cutting: you just need to access to oxygen and fuel gas. (2) With plasma cutting: need plasma power source and air compressor. You can match plasma power supply by yourself, or buy together with the cutter from us, it's optional. If you buy from us, we will connect the wires of plasma power source and CNC cutting machine together, then more conveniently to use.

7. How can I know more about the machine?

We are honored to send you some pictures and vedio about our machine. And we welcome every customer visit our factory.

8. How does your factory do regarding quality control?

Quality is priority. Factory director always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ZDHY, ISO9001 authentication.

9. What are your payment terms?

We support T/T, L/C, Western Union and so on. Other ways can also be received after we both sides discussion and agreement. Any other questions contact us directly!
