YQ Professional Horizontal Type Corrugated Web Assembling Production Line
- 100 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- DOING supply photovoltaic solar panels recycling machine
- four-axis welding machine for commercial sink panel and bowl
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | YQ | Model Number: | YQ |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Main features:
1.H-beam corrugated web horizontal assembly line includes:cut to length machine,corrugated web forming machine,flange and corrugated web transmit machine,robot for welding h-beam,variable cross-section cutting machine,and stack export equipment;
2.Use original welding robot from Italy for welding corrugated web H-beam;
3.The robot will automatically control and complete the whole laser scan,double woring area welding, welding gun change,variable cross-section cutting;
4.The assembly line has high quality and efficiency,and is fully automatic;
5.With this machine,the H-beam output is 10500 ton per shift.
Main techincal parameters:
1.Wok-pice dimension:4-15m
2.Thickeness of web:2-6mm
3.Thickness of flange:10-30mm
4.Welding mode: Double gun double position and welding
5.Dimension: 24000*6500*3500mm
6.Total weight:41T
7.Power:120kw
8.Web height: 30-1500mm
9.Flange height: 150-500mm
10.Control mode: PLC program control
equipment quality promise:
1, the Company's manufacturing facilities are applicable to the relevant national standards and enterprise standards.
2, the company's products are manufactured to meet the technical requirements and parameters should be listed in the specification and to ensure safety and reliability.
3, the company may send engineers to the demand-side participation to help guidance of installation and commissioning of equipment until the machine is qualified and can be put into use. Also we can help the demand side with training equipment operators and maintenance personnel. (Note: The installation and commissioning of equipment abroad, we will take cost in accordance with the cost of a standard international practice)
4 Equipment has 1 year warranty, during the warranty period, the company can track service and maintenance.
Our services:
1.Oversea engineers:
We provide oriented after-sales service including the oversea engineers tranning available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where you are.
2.Learning trip:
We welcome engineers from your side to learn the technical design and normal maintenance here, this will help you easyly to understanding.
3.English Manual:
We have Mannual to show you along with the machine.So you can learn this from the existing document to deeper your knowledge and understanding.
4.Face to face to teacing:
Through internet video face to face for machine teaching,because of the high development in internet,the world has become smaller and you can easy contact us if any assistance needed.
5.Through all the ways,we will guarantee the service quality and ensure you will be well helped anything anywhere.
If youare interested in this machine,please send E-mail to me or contact me directly!
