JF small truck/bus booth painting baking/paint baking room/used spray booth hot sale model on sale
Shenzhen Jiufeng Electromechanical Equipment Co., Ltd. is a professional manufacturer for car spraying, baking and largest automobile spraying/baking booth in South China since Year 2002 . With strong R&D experiences, advanced technology and guarantee quality , JF brand spray booth is getting more and more popular all over the world .
Specification
Model: JF 703
Configuration | |
Inside size |
8600×4000×3500mm(L×W×H) |
Outside size |
8700×5550×4320mm(L×W×H) |
Main door |
Sheet metal manual door, 2+1 folding gate,3000×3400mm(W×H), sheet metal manual big
glass observation window. |
Service door |
One set, with pressure lock, 650×1850mm(W×H), with observation window. |
Basement |
Galvanized plate bending forming. two rows of Strengthening bearing grids and three rows
of metal antiskid diamond plate. Basement height is 300mm. No floor filter under the grids,
with 2 piece of drive-in ramps(900*2000(W×L)) |
Wall board |
Thickness: 50mm, Socket type, width 1150mm, Color steel thickness the inner and
outer:0.426mm, wallboard fill with EPS |
Lighting |
Ceiling light: 10 sets, each set with 3×36W LED tube, Side light: 12sets, each set with
2×36W LED tube , Total Brightness≥1100Lux |
Inlet fan |
1 set of turbo fan, 11kW, air volume: 30000 m3/h. |
Exhaust fan |
1 set of turbo fan, 11kW, air volume: 30000 m3/h, standard exhaust pipe: 3 straight and 1 bend. |
Heating system |
Italian RIELLO G10 diesel burner, stainless steel high efficiency heat exchangers, spray
paint throttle conversion using a pneumatic mechanism. |
Filter system |
Pre-filter,Ceiling sub-high efficiency filter, fiber glass filter |
Roof panel |
Galvanized plate bending forming |
Control system |
Painting, warm painting, baking, baking time setting, lighting, emergency stop switch,
power:380V(220V)/50Hz |
Total power |
24.5Kw |
We are professional manufacturer for 12 years in China
Warranty time: 2 years. During the warranty time, any time, any problem caused by products’ quality,has responsibility to offer free spare parts to customers freely and bear the delivery cost for DHL or TNT Carrier.
Service time: Life long maintenance
Q1: What's the sort of heating types?
JF reply: There are diesel, gas and electricity(infrared lamp) heating.
Q2: Does the JF spray booth with the European design ?
JF reply: Our products are welcomed in Europe. All the spray booths are according to European standard with CE certificate.
Q3: What are range of the voltage and power for JF spray booth when operating?
JF reply: the standard voltage and power for our products is 220V 50HZ 1PH for lights (Residential voltage), 380V 50HZ 3PH for motors (Industrial voltage), we could modify the voltage to suitable for customer's local voltage.
Q4: For the customer-design spray booth for other workpieces, does JF could provide?
JF reply: Absolutely yes, JF has the professional team with 12 years of design experience. JF may design according to customers requirements of spray booth for car, bus, big iron workpieces, wooden furniture etc.
