Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GOLDSHINE
Model Number:
GS324
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GOLDSHINE
Model Number
GS324
Usage
Pressure Sensor
Theory
Resistance Sensor
Output
Other, Analog sensor/Digital sensor
Technical Parameter:
Rated Load: | 80kg |
Sensitivity: | (1.5±0.1%) mV/V |
Combined Error: | ±0.03% F.S |
Creep Error(30min): | ±0.03% F.S |
Zero Balance: | ±1% F.S |
Temp. Effect On Zero: | ±0.03% F.S/10°C |
Temp. Effect On Span: | ±0.03% F.S/10°C |
Input Resistance: | 385±5Ω |
Output Resistance: | 351±2Ω |
Insulation Resistance: | ≥5000MΩ |
Operating Temperature Range: | -30~+70°C |
Maximum Safe Over Load: | 150%F.S |
Ultimate Over Load: | 250%F.S |
Recommend Excitation Voltage: | 10~12V DC |
Maximum Excitation Voltage: | 15V DC |
Sealing Class: | IP67 |
Element Material: | Alloy Steel,Stainless Steel |
Cable: | Length=L:3m |
Citation: | GB/T7551-1997/ OIML R60 |
Mode Of Connection: | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
