SHENTA QTY5-15 Fully Automatic Fly Ash Brick Making Machine in India price

Name: SHENTA QTY5-15 Fully Automatic Fly Ash Brick Making Machine in India price
Brand: SHENTA MACHINE
Price: USD $25,000 - 30,000 / Set

FOB Price

USD $25,000 - $30,000 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Guangzhou or Fangcheng Port
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Hollow Block Making Machine	Brick Raw Material:	Fly Ash
Processing:	Brick Production Line	Method:	Hydraulic Pressure	Automatic:	Yes
Capacity:	9,000~60,000 blocks/shift (8h)	Place of Origin:	Guangxi, China	Brand Name:	SHENTA MACHINE
Model Number:	QTY5-15	Voltage:	380V	Power:	80kW
Dimension(LWH):	3800x1800x3000mm	Certification:	CE, ISO9001:2008, BV	Warranty:	1 Year
After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

Package is suitable for container load and ocean shipping.

Product Description

SHENTA QTY5-15 Fully Automatic Fly Ash Brick Making Machine in India price

I. Characteristic of QTY5-15 fly ash brick making machine

1.The main machine adopt Japanese Mitsubishi PLC controller, has the functions of HMI operation and brick automatic output, automatic reset, lack material and lack plank alarm, easy and humanized operation, the electric parts are provided by well-known company to ensure the safety and stable running;

2.With multifunction feature to produce both the load-bearing brick and non-load-bearing brick, according to change the mouldsto produce different wall bricks, as well as produce multi-hole bricks and road pavers bricks;

3.The main machine utilized the molding method of pressure and high frequency vibration to make the more airtight and solid block, the hydraulic system adopts Taiwan/Japan high quality components; ;

4.The high quality frequency converter can protect the working life, as well as reduce the power consumption.

II. Main specifications of QTY5-15 fly ash brick making machine

Operation Cycle	15~25s	Pallet Size	108055025mm
Brick Height	60~200mm	MainPower Capacity	37Kw
Mixer Model	JS500	Vibration Force	80kN
Net Weight	10t	Main Machine Dimension	386018003000mm
Power Source	3Phase, 380V/50Hz (Special voltage & frequency is available according to your local power source.)

III. Theoretic Productivity of fly ash brick making machine QTY5-15

Brick Type	Dimension	Blocks/Cycle	Blocks/Hour	Blocks/Shift	Remark
Hollow Brick	390190190mm	5	1200	9600
Porous Brick	24011590mm	16	3840	30720
Paver Brick	20010060mm	18	4320	34560
Solid Brick	24011553mm	32	7680	61440

Note: Special brick model is available according to customer demand.

IV. Brick raw material for QTY5-15 fly ash brick making machine

Our brick machine can adopt the following raw materials to make the good quality hollow brick, solid brick and paver brick.

1.Cement: 10%~20%;

2.Sand: 30~40%;

3.Crushed Stone (<5cm): 30~40%;

4.Fly Ash or Additive: ~10% (Fly ash brick making machine)

V. Brick Samples for QTY5-15 fly ash brick making machine

Our brick machine can produce the concrete hollow brick, solid brick, porous brick, paver brick, interlock brick, road traffic stone and so on.

Experienced in selling concrete brick machine to more than 30 different countries, we pack and load the machines well and prevent any damages during transportation, all the key parts are protected by wooden boxes.

I. Factory Ability:

1. Workshop Area: 40,000 square meter;

2. Facility:

CNC Lathe	06 sets	Boring Lathe	02 sets	Shaper	02 sets
Milling Machine	04 sets	Press Brake	02 sets	CNC Flame Cutter	01 set
Crane	10 sets	Shot Blast Machine	01 set	X-ray Inspection Instrument	01 set

II. Quality Control & Certificate:

We adopt the high quality steel materials, and every process will have the strict inspection and test comply with the ISO-9001or CE standard to ensure the machine has perfect performance.

III. Our Achievement:

Until now we have successfully export and handover our brick machine and production line to customers in Vietnam, Indonesia, Angola, India and Papua New Guinea, and acquire the good reputation of user.

IV. Contact Information:

Welcome contact us via below:

Company Profile

Guangxi Shenta Machinery Equipment Co., Ltd.

Nanning SHENTA Machinery Equipment Co., Ltd, established in 1973, is the earliest professional and leading manufacturer of concrete block making machinery. After decades of hard working, we have developed into the high-tech enterprises which integrate the research & development, manufacturing, sales and service. SHENTA factory covers an area of 40,000 square meter, with senior engineers more than 20 people and all kinds of technician more than 200 staff. With an annual production capacity of 500 sets.
SHENTA devoted great care to market planning and development, we have earned ISO9001-2008 Quality Management Certificate in 2008, and awarded the title of "valuing contract and keeping promise" for many years. With the advanced technique, sophisticated technology, strict supervision and perfect service, SHENTA has become the high quality supplier in new building material field.
SHENTA not only distributed in all around China, but also exported to Southeast Asia, Africa, and Oceania etc.
Adhering to the philosophy of "Credit & Honest, dedication & devotion, pragmatism & practice, Innovation & Creation", SHENTA stride forward to construction equipment enterprise of specialization, scale and internationalization, provide strong support of equipment for the new building material, building the solid future for you.

Contact Us

Guangxi Shenta Machinery Equipment Co., Ltd.: Contact nameFang Huang; Phone86-771-3815888; AddressNO.A-6-1,PINGSHAN ER ROAD,MINGYANG INDUSTRY ZONE, NANNING,GUANGXI,P.R.CHINA Nanning,Guangxi
