Melamine Lamination Hot Press
- 10 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Type: | Hot Press Machine | Brand Name: | Xiangying |
Model Number: | TMJ-2400T | Voltage: | 380V | Power(W): | 22KW |
Dimension(L*W*H): | 1400x2600x140mm | Weight: | 36000KG | Certification: | CE ISO |
Warranty: | 1year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
main specification:
Item | 1200T double surface lamination hot press machine Main specification | Technical Data (4'x8') |
1 | Overall Pressure/Oil Pressure | 12000KN |
2 | Feeding direction | Horizontal |
3 | Size of up hot platen | 1400x2600x140mm |
4 | Size of down hot platen | 1400x2600x100mm |
5 | Distance between platen | ≥180mm |
6 | Processing area | 1400*2600mm |
7 | Main cylinder | Φ320mm,6pcs |
8 | No-load closing time | ≤3sec |
9 | Working closing time | ≤5sec |
10 | Frame thickness | 50mm |
11 | Electric form | PLC |
12 | Electric | 380V 50Hz |
13 | Hydraulic valve | Hydraulic station |
14 | Structure form | Frame,welding, completely Transportation |
15 | Feeding mechanism | Feeding truck |
16 | Outputting mechanism | Outfeeding truck |
17 | Weight | 36Ton |
18 | Power | 22KW |
