Short Cycle Lamination Hot-press /for Melamine
US$ 6,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hot Press Machine
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Lamination Molded Door Hot Press /pre-pressUS$ 4,500 - 8,000MOQ: 1 Set -
Iran Melamine Paper /Iran Impregnatived Paper Line/Iran Inpregnatived Melamine Paper MachineUS$ 200,000 - 500,000MOQ: 1 Set
-
Temprature Control Inner Loop Short Cycle Lamination Hot-press 4x8ftUS$ 6,000 - 15,000MOQ: 1 Set
-
Blockboard Lamination Hot Press Use Melamine PaperUS$ 35,000 - 55,000MOQ: 1 Set
-
Wooden Molded Door Hot Press Machine/Mould Plate/Full Automatic Production LineUS$ 4,500 - 8,000MOQ: 1 Set
Condition
New
Type
Hot Press Machine
Place of Origin
Shandong, China
Brand Name
XIANGYING
Model Number
SCL-pr901
Voltage
220v
Power(W)
37kw
Dimension(L*W*H)
3.6x1.3x2.2m
Weight
30T
Certification
iso/9001
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Equipments of short cycle press and details
1,Total pressure:1200KN--2200KN
2,Board size:2440x1220mm
3,Feeding direction: From length side
4,Up/down heating platen size:1400x2600x140/100mm
5,Daylight opening:280mm
6,Main oil cylinder:Ø320mmx6pieces
7,Main oil cylinder working stroke:180mm
8,Closing time with loading:less than 2s
9,thickness of frame steel platen:50+30mm
10,Main motor power:37kw
11,Weight: Approx 30Ton
