Blockboard Lamination Hot Press Use Melamine Paper
US$ 35,000 - 55,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Hot Press Machine
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wooden Molded Door Hot Press Machine/Mould Plate/Full Automatic Production LineUS$ 4,500 - 8,000MOQ: 1 Set -
Chinese Wooden Molded Door Hot Press Machine in Full Automatic Line/soft LineUS$ 4,500 - 8,000MOQ: 1 Set
-
Short Cycle Lamination Hot Press/Production Line in Full Automatic LineNegotiableMOQ: 1 Set
-
Capascity 10000cbm One Year Lamination Hot Press for Plywood /particle Board /mdfUS$ 35,000 - 55,000MOQ: 1 Set
-
Wooden Molded Door Hot Press Machine/Mould Plate /Cushion PadUS$ 4,500 - 8,000MOQ: 1 Set
Condition
New
Type
Hot Press Machine
Place of Origin
Shandong, China
Brand Name
XIANGYING
Model Number
LMH-30
Voltage
380v
Power(W)
220kw
Dimension(L*W*H)
3.8x1.2x4.6m
Weight
26t
Certification
iso/9001
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1,we are manufaturer in China2,we have the full line ,from boiler to sanding machine
Equipments of short cycle press and details/ Blockboard lamination hot press
1.Total pressure: 600KN
2.Board size: 2440x1220mm
3.Feeding direction : From length side
4.Up heating platen size: 1370x2700x52mm
5.Daylight opening: 100mm
6.Main oil cylinder: Ø220mmx6xpcs
7.Main Oil cylinder working stroke: 800mm
8.Closing time with loading:less than 15s
9.Thickness of frame steel platen:35mm
10.Structure:Frame structure,Welded
11.Main motor power:18.5kw
12.Weight:Approx30Ton
