Molded Door Skin Hot Press Machine/Molded Door hot-press
- 15 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Type: | Hot Press Machine | Place of Origin: | Shandong, China |
Brand Name: | Youming | Model Number: | YM-MS | Voltage: | 380 v |
Dimension(L*W*H): | 3.2x1.2x3.6 m | Weight: | 30 T | Certification: | ISO9001 |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Molded Door Skin Hot Press Machine/Molded Door hot-press
Molded door skin hot press machine is used for making melamine door skin or veneer door skin.Door skin can have many choice about the texture which is made by different kind of door moulds.
Molded door skin hot press machine is developed for producing melamine MDF surface of wooden doors. The synchronizer makes all platens going up and down at the same time. Platens can stop at any position according your operation. The pressure and time of holding pressure are adjustable and flexible. You can select the automatic and manual type easily by an electrical switch.
Molded Door Skin Hot Press Machine/Molded Door hot-press
Model | End plate size(ft) | Nominal pressure(KN) | Hot platen size(mm) | Daylight opening(mm) | Main oil cylinder( dia×stroke×pcs) | |
NYJ-800T | 3 daylights | 3×7 | 8000 | 1150×2250×70 | 250 | Φ440×920×4 |
4 daylights | 3×7 | 8000 | 1150×2250×60 | 250 | Φ250×1000×8 | |
5 daylights | 3×7 | 8000 | 1150×2250×60 | 250 | Φ280×1250×6 | |
NYJ-1200T | 3 daylights | 3×7 | 12000 | 1150×2250×70 | 300 | Φ320×920×6 |
4×8 | 1400×2600×70 | |||||
4 daylights | 3×7 | 12000 | 1150×2250×60 | 250 | Φ320×1000×6 | |
4×8 | 1400×2600×60 | |||||
5 daylights | 3×7 | 12000 | 1150×2250×60 | 250 | Φ280×1250×8 | |
4×8 | 1400×2600×60 | |||||
NYJ1400T | 3 daylights | 3×7 | 14000 | 1150×2250×40 | 300 | Φ340×920×6 |
4×8 | 1400×2600×70 | |||||
4 daylights | 3×7 | 14000 | 1150×2250×60 | 250 | Φ340×1000×6 | |
4×8 | 1400×2600×60 | |||||
5 daylights | 3×7 | 14000 | 1150×2250×60 | 250 | Φ340×1250×6 | |
4×8 | 1400×2600×60 | |||||
NYJ-1600T | 3 daylights | 4×8 | 16000 | 1400×2600×70 | 250 | Φ380×920×6 |
4 daylights | 4×8 | 16000 | 1400×2600×60 | 250 | Φ380×1000×6 | |
5 daylights | 4×8 | 16000 | 1400×2600×60 | 250 | Φ380×1250×6 |
Molded Door Skin Hot Press Machine/Molded Door hot-press
Company | Linyi Youming Machinery Manufacturing Co.,Ltd |
Location | located at Lanshan district, Linyi City of Shandong province |
History | Established since 1992, It has beening an aggressive enterprise which integrates woodworking researching,designing ,manufacturing, marketing |
Main products | 1.Particle board production line, 2.Plywood production line 3.MDF production line, Melamine veneer press 4.Mould door equipment etc |
Achievement | our business scope expands extensively both at home and in more than 20 countries such as Vietnam, Malaysia, Pakistan ,Bangladesh, Russia, Turkey and so on. |
