Equipment List:
1. feed reel 2. once dip coater 3. once oven 4. once eject wet 5. once workerchille r 6. twice spread coater 7. twice oven 8. twice eject wet 9. twice workerchille r 10. adjust leaning machine 11. traction engine 12. cutting paper machine 13.lifting platform of piling paper
General Technical Parameter:
| 1 | Work width | 2400mm |
| 2 | Mechanical speed | 3-50m/min |
| 3 | Dry heat funtain | Guiding heat oil |
| 4 | Work temperature | >220℃ |
| 5 | Drying oven length(unit) | 3750mm*3kts+3750mm*5kts |
| 6 | The content of rosin | >60-270% |
| 7 | Volatile content | 6.5-7.5% |
| 8 | Install machine capacity | 180KW |
| 9 | Rosin | Low-pressure melamine resin |
| 10 | Base paper | Wearable paper,Decorative paper,Balanced paper |
Functions and Features:
RS485 digital communication technology used to achieve the man-machine interface (touch screen), PLC and inverter control of communications, replacing the traditional control panel, greatly enhanced the level of the digital machine. Has a good anti-jamming performance, to ensure the stability of the system.
Industrial grade modular design, simple man-machine dialogue, abundant message in both English and Chinese.
High-precision measurement system and network roll-roll, you can precisely control the amount of plastic with the glue evenly and continuously adjustable advantages.
Drive roller, hot are energy efficient inverter control, production and low consumption, synchronization wire-speed stability, low cut paper.
Dual photoelectric transfer partial control of synchronous motor, with a transfer bias stability, stable operation and the advantages of paper.
Cutting the use of coding technology, high precision, accuracy, and can be set arbitrary length.
Oven using high-precision PID temperature control, thermal insulation effect.
Inquiries and statistics throughout the year the day's output.
Advanced automatic tension control system can be arbitrary and automatically adjust the tightness of paper away.
The use of coaxial heating fan design, the production of noise to a minimum. Selection of Japan's imports of motor NSK bearings, to ensure that the work of long-term trouble-free.
Oven heat-free corners and efficient utilization of geothermal energy, temperature control accuracy of ± 1 ℃.
Product information ok.
