New Multifunction 7 inch touch screen IP camera tester
Feartures ip camera tester cctv tester ip camera tester
1.7 inch touch screen, 800*600 resolution. New !
2. Capacitive touch screen, OSD menu,
3. Touch screen and key operation
4. Built-in WIFI, wireless network camera test. New !
5. Support 1080P HD camera
6. Support ONVIFcamera, and Support DAHUA, Haikang, KEDA, Samsung, HIKVISION and TIANDY camera. Ect
7. Support running the mobile phone or tablet mobile client software of the IP camera manufacturers.
8. Image can rotate 180 degrees. New !
9. Display real resolution of the IP camera images
10. Video screenshot, video recording, files named and save, easy to find. New !
11. Support network PTZ controller (ONVIF)
12. Support 1080P HD video files and MKV/MP4 media files play
13. PTZ controller, Photograph, Video record, Record playback
14. Video level meter, Video PEAK lever, SYNC level, COLOR BURST measurement New !
15. Optical Power Meter, it can measure the optical power value*(Optional)
16. Visual fault locator, to test fiber's bending and breakage * (Optional)
17. TDR cable test, Digital Multi-meter, optical power meter, and Visual fault locator, etc function; NEW (Optional) New !
18. Digital video color bar output, analog video color bar and testing image output NEW (Optional) New !
19. POE voltage measurement, PING test, IP address scan, port flashing etc
20. PoE DC48V power output, Max power 24W; New !
21.12V /2A power output New !
22.5V 2A power output, as the power bank New !
23. HDMI output, 1920*1080P Resolution; New !
24. Audio in /out
25. LED lamp, calculators, music players and other application tools
26. Support customers self update software
27. Lithium Ion Polymer Battery, working time lasts 16 hours
Specification ip camera tester cctv tester ip camera tester
Model |
JY-IP02T |
||||
Display: |
7 inch touch Capacitive touch screen,800*600 resolution |
||||
Communication port |
10/100M adjustable,RJ45 |
||||
IP camera |
Customized: ONVIF,ACTi,DA HUA(IPC-HFW2100P),HIKVISION (DS-2CD864-E13),SAMSUNG,(SNZ-5200),TIANDY( TD-NC9200S2),Kada(IPC120L),HONEYWELL(HICC-2300T),AIPU,etc |
||||
Video in/out |
1 channel BNC Input & 1 channel Output,support PAL/NTSC format |
||||
Video level meter* |
Video PEAK lever,SYNC level, COLOR BURST measurement |
||||
DC12V power output |
Output temporary 12V power for camera, the current is near 1A. |
||||
Audio input |
test the pickup and other audio equipments on the front-end |
||||
PTZ Protocol |
Support morethan 30 protocols ,such as PELCO-D/P,Samsung,Panasonic,Lilin,Yaan,etc. BaudRate:600-115200bps. Support RS232/RS485 |
||||
Color bar generator |
Output one channel PAL/NTSC color bar video signal for testing monitor or video cable |
||||
UTP Cable tester |
Test UTP cable connection status and display in the screen. Read the number of the test box |
||||
Data Monitor |
Captures and analyzes the command data from controlling device |
||||
Photograph, Video record, Record playback |
Snapshot, Video record, views the storage file in the SD card. |
||||
Network testing |
IP address scan, Linkmonitor, PING test. Scan the ID of the PTZ camera quickly |
||||
Cable scan |
Search the cable by the audio signal |
||||
POE tester |
Display the power supply voltage and cable connection states |
||||
Digital Multimeter |
Voltage, current, resistance and capacitance measuring, continuity testing, diode test |
||||
Optical power meter |
Wavelength(nm):850/1300/1310/1490/1550/1625nm Measure range(dBm):-70~+10dBm |
||||
Visual fault locator |
Test fiber’s bending and breakage ( SM and MM fiber) |
||||
TDR Tester |
breakpoint and short circuit measurement(BNC cable, telephone cable) |
||||
POWER | |||||
Power Adapter |
DC 5V(2.5-3.0A) |
||||
Battery |
Built-in 3.7V Lithium polymer battery, 12000mAh |
||||
Rechargeable |
After charging 8-10 hours, working time lasts 16 hours |
||||
Parameter | |||||
Operation setting |
Capacitive touch screen. English/Chinese OSD menu |
||||
Auto off |
1-30 (mins) |
||||
Key tone |
On/Off |
||||
General | |||||
Working Temperature |
-10°C---+50°C |
||||
Working Humidity |
30%-90% |
||||
Dimension/Weight |
231mm x 172mm x 52mm / 1.26Kg |
||||
1.First send us an inquiry for quote or through trademanager,please be specific on products catagoy,products name ,color,quantity and your requirement about the products.
2.Then we will response to your request within 24 hours with an quotation sheet,payment term and delivery time .
3.After confirming all the information by you,we will prepare a copy of PI(proforma Invoice) or purchase agreement,we will attached the bank information in the PI.
4.After confirm your payment, we will arrange the products for you as soon as possible
Shenzhen Joney Security Technology Co.,Ltd provide various specification
and items of CCTV cameras,PTZ cameras, IP cameras, Standalone DVR,
DVR card, related cctv accessories, Fingerprint device, access control system, Alarm products.
