WV-S2572L I-PRO Extreme H.265 Dome Network Camera

4K Vandal Resistant Outdoor Dome Network Camera

4K (3,840 x 2,160) up to 30fps

Intelligent Auto

Color night vision (0.006 to 0.09 lx)

H.265 Smart Coding

i-VMD License Bundled

FIPS140-2 CAVP compliant

*Using encryption module standardized by FIPS publication 140-2

NDAA Compliant

Camera

COMPONENT SPECIFICATION

Image Sensor 1/1.8 type CMOS image sensor

Minimum Illumination Color : 0.09 lx, BW : 0.05 lx

(F1.5, Maximum shutter : Off (1/30s), AGC : 11)

BW : 0 lx

(F1.5, Maximum shutter : Off (1/30 s), AGC : 11, when the IR LED is lit)

Color : 0.006 lx, BW : 0.003 lx

(F1.5, Maximum shutter : max. 16/30s, AGC : 11)

White Balance ATW1/ ATW2/ AWC

Shutter Speed [30fps mode] 1/30 Fix to 1/10000 Fix [25fps mode] 1/25 Fix to 1/10000 Fix

Intelligent Auto On / Off

Super Dynamic On / Off, The level can be set in the range of 0 to 31.

Dynamic Range Max. 132 dB (Super Dynamic : On, Level : 31)

Adaptive Black Stretch The level can be set in the range of 0 to 255.

Back Light Compensation/High Light Compensation BLC (Back light compensation) / HLC (High light compensation) / Off

The level can be set in the range of 0 to 31.

(only when Super dynamic / Intelligent Auto : Off)

Fog Compensation On / Off, The level can be set in the range of 0 to 8

(only when Intelligent auto / auto contrast adjust : Off)

Maximum Gain (AGC) The level can be set in the range of 0 to 11.

Color/BW (ICR) Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC)

IR LED Light High / Middle / Low / Off,

Maximum irradiation distance : 40 m {Approx. 131 ft}

Digital Noise Reduction The level can be set in the range of 0 to 255.

Video Motion Detection (VMD) On / Off, 4 areas available

Scene Change Detection(SCD) On / Off, 1 areas available

Intelligent VMD (i-VMD) Type 7 *Bundled License

Privacy Zone On / Off, Up to 8 zones available

Image Rotation 0 ° (Off) / 90 °/ 180 ° (Upside-down)/ 270 °

Camera Title (OSD) On / Off, Up to 20 characters (alphanumeric characters, marks)

Lens

COMPONENT SPECIFICATION

Optical Zoom 2.0x (Motorized zoom / Motorized focus)

Extra optical zoom 6.0x (when resolution is 1280x720)

Digital (electronic) zoom Choose from 3 levels of x1, x2, x4

Focal length 4.3 mm - 8.6 mm {5/32 inches – 11/32 inches}

Maximum Aperture Ratio 1 : 1.5 (WIDE) – 1 : 2.4 (TELE)

Focusing Range 1 m {39-3/8 inches} – ∞

Angular Field of View [16 : 9 mode] *[4:3 mode] is not supported.

Horizontal : 52° (TELE) – 101° (WIDE), Vertical: 29° (TELE) – 55° (WIDE)

DORI

COMPONENT SPECIFICATION

Detect (25ppm / 8ppf) Wide: 63.31 m / 207.71 ft, Tele: 157.46 m / 516.61 ft

Observe (62.5ppm / 19ppf) Wide: 25.32 m / 83.08 ft, Tele: 62.99 m / 206.64 ft

Recognize (125ppm / 38ppf Wide: 12.66 m / 41.54 ft, Tele: 31.49 m / 103.32 ft

Identify (250ppm / 76ppf) Wide: 6.33 m / 20.77 ft, Tele: 15.75 m / 51.66 ft

Adjusting Angle

COMPONENT SPECIFICATION

Adjusting Angle Horizontal (PAN) angle : ±180°, Vertical (TILT) angle : -30 to +85°,

Azimuth (YAW) angle : ±100°

Browser GUI

COMPONENT SPECIFICATION

Camera Control Brightness, AUX On / Off

Audio Mic (Line) Input : On / Off Volume adjustment : Low / Middle / High

Audio Output : On / Off Volume adjustment : Low / Middle / High

GUI / Setup Menu Language English, Italian, French, German, Spanish, Portuguese, Russian, Chinese, Japanese

Network

COMPONENT SPECIFICATION

Network IF 10Base-T / 100Base-TX, RJ45 connector

Resolution H.265/ H.264/ JPEG (MJPEG) [16 : 9 mode] *[4:3 mode] is not supported.

3840×2160, 2560×1440, 1920×1080, 1280×720, 640×360, 320×180

H.265/H.264 [Transmission Mode]

Constant bit rate / VBR / Frame rate / Best effort

[Transmission Type]

Unicast port (AUTO)/ Unicast port (MANUAL)/ Multicast

JPEG [Image Quality]

10 steps

Smart Coding GOP (Group of pictures) control :

On (Frame rate control)* / On (Advanced)* / On (Mid) / On (Low) / Off

*On (Frame rate control) and On (Advanced) are only available with H.265.

Auto VIQS : On / Off

Audio Compression G.726 (ADPCM) : 16 kbps / 32 kbps G.711 : 64 kbps

AAC-LC : 64 kbps / 96 kbps / 128 kbps

Audio Transmission Mode Off / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)

Supported Protocol IPv6 : TCP/IP, UDP/IP, HTTP, HTTPS, SMTP, DNS, NTP, SNMP, DHCPv6, RTP, MLD,

ICMP, ARP, IEEE 802.1X, DiffServ, SSL/TLS, SRTP, SFTP, MQTT, LLDP

IPv4 : TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP,

SMTP, DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP,

ARP, IEEE 802.1X, DiffServ, SSL/TLS, SRTP, SFTP, MQTT, LLDP

No. of Simultaneous Users Up to 14 users (Depends on network conditions)

SDXC/SDHC/SD Memory Card H.265 / H.264 recording :

Manual REC / Alarm REC (Pre/Post) / Schedule REC / Backup upon network failure

JPEG recording : Manual REC / Alarm REC (Pre/Post)

Compatible SDXC/SDHC/SD Memory Card :

Panasonic 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB*, 64 GB**, 128 GB**, 256 GB**model

*SDHC card, ** SDXC card (except miniSD card and microSD card)

Mobile Terminal Compatibility iPad, iPhone, AndroidTM terminals

ONVIF® Profile G / S / T

Alarm

COMPONENT SPECIFICATION

Alarm Source 3 terminals input, VMD alarm, SCD alarm, Command alarm

Alarm Actions SDXC/SDHC/SD memory recording, E-mail notification, HTTP alarm notification,

Indication on browser, TCP alarm notification output

Input/Output

COMPONENT SPECIFICATION

Monitor Output (for Adjustment) VBS : 1.0 V [p-p] / 75 Ω, composite, ø3.5 mm mini jack

An NTSC or PAL signal can be outputted from camera

Audio input ø3.5 mm stereo mini jack

For microphone input : Recommended applicable microphone : Plug-in power type

(Sensitivity of microphone : -48 dB±3 dB (0 dB=1 V/Pa, 1 kHz))

Input impedance : Approx. 2 kΩ (unbalanced)

Supply voltage : 2.5 V ±0.5 V

For line input : Input level: Approx. –10 dBV

Audio Output ø3.5 mm stereo mini jack (Audio output is monaural.)

Output impedance : Approx. 600 Ω (unbalanced)

Output level : –20 dBV

External I/O Terminals ALARM IN 1(Alarm input 1/ Black & white input/ Auto time adjustment input) (x1)

ALARM IN 2 (Alarm input 2/ ALARM OUT) (x1) , ALARM IN 3 (Alarm input 3/ AUX OUT) (x1)

General

COMPONENT SPECIFICATION

Safety UL (UL60950-1), c-UL (CSA C22.2 No.60950-1), CE, IEC60950-1

EMC FCC (Part15 ClassA), ICES003 ClassA, EN55032 ClassB, EN55024

Power Source and Power Consumption DC power supply : DC 12 V 980 mA/Approx. 11.8 W

PoE (IEEE802.3af compliant) Device : DC48 V 260 mA/ Approx. 12.5 W (Class 0 device

Ambient Operating Temperature -40 °C to +60 °C (-40 °F to +140 °F)*10

(Power On range : –30 °C to +60 °C {–22 °F to +140 °F})

Ambient Operating Humidity 10 to 100 % (no condensation)

Dehumidification Device Temish element+Fan/Heater

Anti-Condensation System Temish element

Water and Dust Resistance IP66 (IEC60529), Type 4X(UL50E), NEMA 4X compliant

Shock Resistance 50J (IEC 60068-2-75 compliant), IK10 (IEC 62262)

Wind Resistance Up to 40 m/s {approx. 89 mph}

Dimensions When using base bracket : ø164 mm × 139 mm (H) {ø6-15/32 inches × 5-15/32 inches (H)}

Dome radius 42 mm {1-21/32 inches}

When using attachment plate only : ø154 mm × 103 mm (H) {ø6-1/16 inches × 4-1/16 inches (H)}

Dome radius 42 mm {1-21/32 inches}

Mass When using base bracket : Approx. 1.6 kg {3.53 lbs}

When using attachment plate only : Approx. 1.2 kg {2.65 lbs}

Finish Main body : Aluminum die cast, i-PRO white

Outer fixing screws : Stainless steel (Corrosion-resistant treatment)

Dome cover : Polycarbonate resin, Clear
