Specifications
1.Logo attaching machine included2.Power use:50kw/h
3.Max out180kg/h
4.Max speed 5m/min.
pvc window profile machine
PVC window profile machine
Applications:
For production of pvc/upvc window and door frame profiles,width within 300mm
Advantages:
- Unique in design and adopts BM detachment-type high-speed screw.
- High automation,easy operation,continuous production,stadility.
- Good in heat resistance,aging resistance, environmental stress crack resistance and creep resistance.
Technical parameters:
Components |
SJSZ-65/132 Conical two-screw extruder,Head Mould,Calibrating table,Haul-off machine and Cutter,Film attaching machine,Stacker |
Calibrating mode |
Vacuum Calibrating |
Cooling mode |
Water cooling |
Calibrating table length |
6000mm |
Hauling Speed(m/min) |
1-6 |
Stacker Length |
6000mm |
Install dimension(L,W,H) |
22000mm*1600mm*2600mm |
Equipment Weight |
12 T |
Package |
Wooden pallet,case and PE film |
Transportation |
Container 40'GP |
Electric Appliances:(can be choosed by clients)
Inverter—Siemens/ABB Temperature controller—OMRON/RKC Contactor—Siemens
Operation system—Siemens PLC(touch screen) or keyboard control
Pictures for reference:
