PU PVC PUR Medical catheter Extrusion Line / breathing tube machine

Specifications

Medical tube extrusion line
1. high precision
2.Aseptic technique
3. High Speed

   Qingdao Shine East Plastic Machinery Co., Ltd, a high-tech join-stock enterprise, integrates scientific research development, technology transfer, production and sale. In addition, it is the unit for accomplishing key promotion projects of science and technology result in construction department.

   Application:
This production line can produce trachea cannula, center vein vessel, anaesthesia tube, perfusion tube, catheter ,etc.
Medical catheter Extrusion Line
The whole line is made up by extruder, die and head, water cooling tank, printing machine, haul-off machine, cutting machine.
main technical parameter:

Model	Screw dia.(mm)	L/D	Drive power (kw)	Vacuum power (KW)	Cutting power(KW)	Output range( Kg/h)	Center height (mm)
JD-S25	25	25-30	2.2	0.5	0.75	2-4	1000
JD-SJ30	30	25-30	3.7	0.75	0.75	3-6	1000
JD-SJ35	35	25-30	5.5	0.75	0.75	5-10	1000
JD-SJ40	40	25-30	7.5	0.75	1	8-15	1000
JD-SJ45	45	25-30	11	1.5	1	10-30	1000
JD-SJ50	50	25-30	15	1.5	1	20-50	1000
JD-SJ55	55	25-30	18.5	1.5	1	25-55	1000
JD-SJ60	60	25-30	22	1.5	1	30-60	1000





Pre-sale



We provide presales service in various forms, for example, making investment budget, manufacturing planning, etc. So that customers make a reasonable plan with less cost.



In-sale



Detailed design of lay-out that is the position of the procession

Technological information of the machine you want

Schedule about design, manufacturing and installation

Working & Producing progression

Training course for the technician so that the installation is safe and standard



After-sale



For customers buying our products, we provide them free training so that they can use and maintain

the machine independently.  Our Warranty is 1 year for whole machinery. We will provide the technical

 advice and find the solution immediately for you when the machine is in trouble-shoot. For those wear parts, we guarantee the high quality parts for long-term supply.

   Pallet,the material of pallet is stainless steel pipe the surface of each part of machinery covered film together with one set of packing list in English wooden crate,under fumigation treatment,together with one set of packing list in English partial shipment allowed container shipment allowed before delivery.We will send the dimension&weight of machinery to customer to help them choose suitable container. (also can be according to customer demand)



For choosing proper machine and saving your time, please read these bellow guides carefully



1). What kinds of plastic machinery do you need ? Or what material do you want to process?

2). What capacity do you want? (tons per hour )

3).what is the max and min size of the finish prducts For example, the diameter of pipe(inch or mm); thickness of pipe wall(mm); width and thickness of sheet (mm)? If profile product, you’d better offer the picture of sample or drawing of sample.

4).what is the electric device you need ? Siemens,Omrn or domestic ?

5) When do you want the machine? (times for delivery)

6) Other requirements about the machine you want.

7) Please inform us your voltage, all we offer is 380V/3P/50HZ
