Specifications
1.Pipe range:20-63mm,2.Extruder Qty:3 sets,
3.Power:120kw,
pipe machine manufacture line
Qingdao Shine East Plastic Machinery Co., Ltd, a high-tech join-stock enterprise, integrates scientific research development, technology transfer, production and sale. In addition, it is the unit for accomplishing key promotion projects of science and technology result in construction department.
20-63mm Glass fiber PPR plastic pipe machine manufacture
Features of pipe machine manufacture line:
1. Equipped ith polyolefin purposed single-screw extruder; it has the characters of quick extruding, high efficiency and so on.
2. The specially designed co-extrusion die head is reasonable in flow channel, smooth in both internal and external walls, and small in internal stress.
3. Pipe diameter is among 20-160mm and production speed reaches to 18m/min.
4.One unit serves several purposes. It can produce common PP-R, Nanometer anti-bacteria pipe, PE-RT and PE-X.
5. If added one co-extrusion engine and die on original base, it can produce PP-R fiberglass reinforced composite pip
Process line of pipe machine manufacture line:
Raw material +master batches → mixing→vacuum feeding → material dryness → single screw extruder → single screw extruder → single screw extruder → color string extruder → spiral co-extrusion mould → calibrator → spray vacuum calibration tank → spray cooling water tank → spray-code printer → belt haul-off → no-dust cutter → pipe rack→finished product inspecting &packing
Technical parameters:
Model |
Screw diameter |
L/D |
Extruder |
Pipe range |
Capacity (kg/h) |
Power(km) |
Total power |
Line length |
FP-PPR-63A |
50mm |
33:1 |
4 |
20-63 |
100-200 |
22*3 |
120 |
30 |
FR-PPR-63B |
65mm,50mm |
33:1 |
3 |
20-63 |
100-180 |
37*1,22*1 |
110 |
30 |
PR-PPR-110A |
65mm |
33:1 |
4 |
20-110 |
180-300 |
37*3 |
190 |
38 |
FR-PPR-110B |
75mm,65mm |
33:1 |
3 |
20-110 |
150-200 |
55*1,37*1 |
180 |
38 |
Production in details:
Pallet,the material of pallet is stainless steel pipe the surface of each part of machinery covered film together with one set of packing list in English wooden crate,under fumigation treatment,together with one set of packing list in English partial shipment allowed container shipment allowed before delivery.We will send the dimension&weight of machinery to customer to help them choose suitable container. (also can be according to customer demand)
Pre-sale
We provide presales service in various forms, for example, making investment budget, manufacturing planning, etc. So that customers make a reasonable plan with less cost.
In-sale
Detailed design of lay-out that is the position of the procession
Technological information of the machine you want
Schedule about design, manufacturing and installation
Working & Producing progression
Training course for the technician so that the installation is safe and standard
After-sale
For customers buying our products, we provide them free training so that they can use and maintain
the machine independently. Our Warranty is 1 year for whole machinery. We will provide the technical
advice and find the solution immediately for you when the machine is in trouble-shoot. For those wear parts, we guarantee the high quality parts for long-term supply.
For choosing proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (tons per hour )
3).what is the max and min size of the finish prducts For example, the diameter of pipe(inch or mm); thickness of pipe wall(mm); width and thickness of sheet (mm)? If profile product, you’d better offer the picture of sample or drawing of sample.
4).what is the electric device you need ? Siemens,Omrn or domestic ?
5) When do you want the machine? (times for delivery)
6) Other requirements about the machine you want.
7) Please inform us your voltage, all we offer is 380V/3P/50HZ
