Specifications
maquina de corte laser de caucho1.CE FDA certificate
2.CCD camera
3.DSP control system
4.USB interface
maquina de corte laser de caucho
Features:
1. Use high speed DSP control system
2. Taiwan Linear square guide
3. Double plain bearing
4. High power driver and motors
5. Y axis use two motors and drivers which enhance the driving force.
Applicable Materials:
Material |
Cut |
Engrave |
Acrylic | Plexiglass | Pmma| Perspex |
♦ |
♦ |
Organic board | Double color plate |
♦ |
♦ |
Wood | Bamboo | Veneer | MDF |
♦ |
♦ |
Leather |Pig leather |Cow Leather |sheep leather |
♦ |
♦ |
Fabric |Cloth | Textile |
♦ |
♦ |
Wool Felt |
♦ |
♦ |
Paper | Cardboard | Chipboard|Press Board |
♦ |
♦ |
Ceramic | Tile| Marble |
|
♦ |
Plastic |
♦ |
♦ |
Fiber glass |
|
♦ |
Technical parameter
Model |
Laser cutting machine SK1280 |
Working area |
1200*800mm |
Laser tube type |
Sealed CO2 laser tube, water-cooling, 10.6um |
Laser tube power |
60W/80W/100W/135W/150W |
Laser tube life |
1500 hours |
Max engraving speed |
0-72000mm/min |
Cutting speed |
0-40000mm/min |
Resolution ration |
≤4000 dpi |
Laser tube cooling |
Water cooling |
Supported graphics |
BMP,HPGL,PLT,DST,DXP and AI |
Driving system |
Stepper |
Power supply |
AC110-220V 50-60HZ |
360° slope engrave |
Yes |
Operating system |
Windows98/ME/2000/XP/VISTA/2007 |
Min, shaping character |
Chinese 2mm*2mm,English 1mm*1mm |
Assistant equipment |
Exhuast-fans, water pump, air pump |
Operating temperature |
0°C~45°C |
Operating humidity |
5%~95% |
Computer interface |
USB port and Standard printer port |
Gross weight |
400kgs |
Package size |
182*137*130cm |
Samples:
Spare parts:
Models of our laser cutting and engraving machine:
Laser cutting and engraving machine----Jinan Suke Science&Technology Co.,Ltd | |||
Model |
Working area |
Dimension |
Net weight |
SK3030 |
300*300mm |
80*60*27cm |
33kg |
SK5030 |
500*300mm |
91*69*58cm |
80kg |
SK6040 |
600*400mm |
145*85*106cm |
80kg |
SK9060 |
900*600mm |
177*101*106cm |
300kg |
SK1280 |
1200*800mm |
172*127*106cm |
350kg |
SK1290 |
1200*900mm |
172*137*106cm |
370kg |
SK1490 |
1400*900mm |
192*130*106cm |
400kg |
Warranty terms:
1. 1 year for the whole machine
2. 3 months for laser tuber,lens and mirror
3. 6 months for equipments outfit, such as water pump, fan, air pump,ect
For more information,please feel free to contact with me!skype:sukelaser3
Looking for agents all the world!
