co2 laser machine trophy engraving machines

Specifications

co2 laser machine trophy engraving machines
1.40w/60w laser tube
2.LCD panel
3.Front andrear delivery

co2 laser machine trophy engraving machines

Features:

1.Has motorized up&down platform.

2.40w/60w laser tube.

3.DSP control system.



Applicable materials:

Material	Cut	Engrave
Acrylic | Plexiglass | Pmma| Perspex	♦	♦
Organic board | Double color plate	♦	♦
Wood | Bamboo | Veneer | MDF	♦	♦
Leather |Pig leather |Cow Leather |sheep leather	♦	♦
Fabric |Cloth | Textile	♦	♦
Wool Felt	♦	♦
Paper | Cardboard | Chipboard|Press Board	♦	♦
Ceramic | Tile| Marble		♦
Plastic	♦	♦
Fiber glass		♦



Technical parameter:



Model	Laser engraving machine SK5030
Working area	500*300mm
Laser tube type	Sealed CO2 laser tube, water-cooling, 10.6um
Laser tube power	40W/60W(can be optional)
Laser tube life	1500 hours
Engraving speed	60000mm/min
Cutting speed	30000mm/min
Repositioning precision	0.01mm
Working voltage	AC110-220V 50-60HZ
Min shaping character	Chinese 2mm*2mm,English 1mm*1mm
Supported graphics	BMP,HPGL,PLT,DST,DXP and AI
Software supported	CorelDraw,AutoCAD,Photoshop
Control system	DSP
Driving mode	stepper
Resolution ratio	≤4000 dpi
360° slope engrave	Yes
Cooling system	Water-cooling and protection system
Operating temperature	0-45
Operating humidity	5-95%
Gross weight	250kgs
Package size	152*97*130cm







Spare parts:





(1) Lens and mirrors:

 Sezn or GaAs materials lens, Mo materials mirrors, easy to clean.

 (2) reci brand laser tube

 Good beam mode, 8000~10000 hours lifetime.

 (3) High speed Step motor

 Working steadily and with high move accuracy.

 (4).Emergency stop
Turn off the machine immediately when there is an accident

 (5). DSP System LCD panel
Set speed, power, and more directly from the LCD panel.

 (6).Honey comb table

 Allows the laser beam to pass through the material you are cutting and reduces underside reflections

 (7).Red Dot Position

 Make the laser beam "visible"

 (8).Color layer setting
Change the working speeds and power by using color settings.

 (9). Up and down platform

 Control the table up/down from LCD panel ( Z axis)directly

 (10).Water protection

Laser will stop working if the water cooling system is not working

 (11).Mirror mount

 Easily re-adjusting  mirror mounts

 (12).High quality rails

 Keep the engraving/cutting precise and very durable.

 Sample:





Package:





Your customized machines are available!





  For more information,please feel free to contact me!skype:sukelaser3
