HIGH SPEED BLISTER PACKING MACHINE FOR ALU-PVC OR ALU-ALU BLISTER
US$ 1 - 100,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Commodity, Food, Other, Medical, Chemical, Commodity, Food, Machinery & Hardware, Medical
Automatic Grade:
Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ALU-PLASTIC FULLY AUTOMATIC BLISTER PACKAGING MACHINESUS$ 1 - 100,000MOQ: 1 Set -
DPP-250A Automatic Alu PVC Blister Packaging MachineUS$ 1 - 100,000MOQ: 1 Set
-
SMALL ALU-PVC AUTOMATIC BLISTER PACKING MACHINESUS$ 1 - 100,000MOQ: 1 Set
-
ALU-ALU OR ALU-PVC BLISTER PACKAGING MACHINESUS$ 1 - 100,000MOQ: 1 Set
-
SMALL ALU-ALU BLISTER PACKING MACHINEUS$ 1 - 100,000MOQ: 1 Set
Condition
New
Application
Chemical, Commodity, Food, Other, Medical, Chemical, Commodity, Food, Machinery & Hardware, Medical
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380V
Power
14kw
Place of Origin
Jiangsu, China
Brand Name
HUALE MACHINERY
Model Number
DPP-260G
Dimension(L*W*H)
5600*900*1750mm
Weight
2200KG
Certification
CE, ISO9001
Warranty
ONE YEAR
After-sales Service Provided
Engineers available to service machinery overseas
Product Name: HIGH SPEED BLISTER PACKING MACHINE FOR ALU-PVC OR ALU-ALU BLISTER
High Speed Flat Type Aluminum Plastic Blister Packing Machine is our advanced equipment designed under updated improvement.It adopts the integral technology applying frequency inverter for speed control with mechanism, electricity, optical and pneumatic on the machine. Its design is in strict compliance with GMP standard and leading in the domestic blister packing industry. Featuring advanced functions, easy operation, high output, and the machine is the best packing equipment for largeand medium size pharmaceutical enterprises, food supplement and food industry.
MAIN TECHNICAL PARAMETERS
| Item/Model | DPP-260G | |
|
Punching Frequency (Standard size 57*80) |
20-100 cutting/min | |
| Max.Forming Area And Depth | 250*200*20mm | |
| Adjustable Pulling Length | 30-220mm | |
| Blister Plate Size | Design according to customers' requirements | |
|
Packaging Material (I.D.Ø75) |
PVC | (015-0.4)*260*(Ø400)mm |
| PTP | (0.02-0.15)*260*(Ø250)mm |
|
| Paper | (50-100)gsm*260*(Ø300)mm | |
| Power | 380V 50Hz 14KW (Three phase) | |
| Air compressor | 0.6-0.8Mpa≥0.25m3/min(Self-prepared) | |
| Mould cooling | Recycle water or circulating water consumption:60-100L/h | |
| Dimension(L*W*H) | 5600*900*1750mm(Including foundation) | |
| Dimension for each part | 2300*720*1600mm(Front) | |
| 1500*900*1750mm(Middle) | ||
| 1800*900*1750mm(Back) | ||
| Weight | (About)2200kg | |
MACHINE ADVANTAGE
- The machine used of closed structure, new safety protection design. Adopts top brand PLC controller with touch screen displayed in double languages, frequency inverter for speed control, servo traction which can ensure the length of blister traction adjustable within the range.
- The machine comes with PVC quick installation and complete set guide way.
- With thermal temperature control and inspection, main machine over load protection, PVC and PTP packing material position inspection, feeder material position inspection, failure automatic debug and alarm, automatic protection and stop running.
- The machine adopts newly designed speed adjustable double-hopper system feeder with high precision optical control for high efficiency feeding. It is suitable for different blister sheet style and irregular shape material feeding (Special feeder can be designed according client’s requirement.)
- All working station of the machine adopts flat type structure with mould trapezoid style fixing, forward and backward makes much more easier and safer while operation and changing mould.
- It adopts contact style preheating, compressed air blow forming, upper and lower mould dot sealing, double servo pulling system, double print register controlling system makes perfect packaging.
- The cutting edge between blister are only 1mm, it saves more packing material and protect our environment.
- Discharging finished product in right order, automatic collection of bad products, auto rewinding of strap material to ensure easy collection.
- The machine has been designed into separated body (three parts) which can disassembled for easier move into lifts or workshops.
NEW FEEDER
- Under the control of the quantity of material, can keep the disc brushing not too full, filling the products more accurately
- Moderate material can keep PVC not deformated, make machine operate more stable
