ACSR Conductor Gopher25 MM2

Name: ACSR Conductor Gopher25 MM2
Brand: Sanhe
Availability: InStock

FOB Price

US$ 0.2 - 3.6 / Meter

100 Meters(Min. Order)

Port Qingdao
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Sanhe
Model Number	acsr	Insulation Material	Other, Non
Type	High Voltage	Application	Overhead
Conductor Material	Aluminum	Jacket	Other, Non

Product Description

Specifications

ACSR Conductor Gopher25 MM2
1. Best price in same quality.
2. Best quality in same price
3. Good after-sales service

ACSR Conductor Gopher25 MM2

BS-215-2-70 ACSR
Code nane	Nominal Area	Stranding &Wire Diameter				Approximate overall diameter	Section Area			Approximate weight
	Nominal Area	Aluminum		Steel		Approximate overall diameter	Aluminum	Steel	Total	Approximate weight
	mm²	No.	mm	No.	mm	mm	mm²	mm²	mm²	Kg/km
Rabbit	50	6	3.35	1	3.35	10.05	52.9	8.8	61.7	214.1
Dog	100	6	4.72	7	1.57	14.15	105	13.6	118.5	394.7
Gopher	25	6	2.36	0	2.36	7.08	26.2	0	26.2	72.1
Weasel	30	6	2.59	1	2.59	7.77	31.6	5.3	36.9	128
Ferret	40	6	3	1	3	9	42.4	7.1	49.5	171.7
Horse	70	12	2.79	7	2.79	13.95	73.4	42.8	116.2	538.1
Wolf	150	30	2.59	7	2.59	18.13	158.1	36.9	194.9	725.9
Dingo	150	18	3.35	1	3.35	16.75	158.7	8.8	167.5	507.4
Lynx	175	30	2.79	7	2.79	19.53	183.4	42.8	226.2	842.4
Caracal	175	18	3.61	1	3.61	18.05	184.2	10.2	194.5	589.2

Company infomation

Zhengzhou Sanhe Cable Co.,LTD was founded in 2008, which is a professional manufacturer and expoarter of cables for about 8 years, serving overseas clients only.

As there are many aluminium minerals in and around our city, cables with aluminium conductor are our main products, including AAC, AAAC, ACSR, ABC overheas cable with PVC/XLPE/PE insulated as well as concentric cable.

Our clients are mainly from Asia, Middle East, Latin-America, etc. Welcome your inquiry.

Certifications:

As a professional cable manufactuer, all our products have passed the ISO 9001, CCC and ISO14001 certifications.

Contact with us

Friends, if any interest, pls feel free to contact us.

Your most sincere friend Coco is always here waiting for you.

Contact Us

Zhengzhou Sanhe Cable Co., Ltd.: Contact nameJames Yuan
Chat Now; Phone86-371-69176007; AddressThe cross of Dong Er street and CBD out circle, Zhengzhou, Henan
