The photocontroller JL-225 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.
This product is designed with electronic circuits with sensor of photodiode and a surge arrester (MOV) is provided. Its quicker response with time delay of 3-20 seconds offers easy-to-test feature. Especially, model JL-225C provides a wide voltage range for customer applications under almost power supplies.
Further, a preset 3-20 seconds time-delay might avoid mis-operation due to spotlight or lightning during the night time.
This product provides twist lock terminals meeting the requirements of ANSI C136.10-1996 and the Standard for Plug-In, Locking Type Photocontrols for Use with Area Lighting UL773, 4th Edition, dated Jan.19th, 1995,
Model |
JL-225A |
JL-225B |
JL-225C |
Rated Voltage |
110-120VAC |
220~240VAC |
110-277VAC |
Applicable Voltage Range |
100-140VAC |
200~260VAC |
105-305VAC |
Rated Frequency |
50/60Hz |
||
Rated Loading |
1000W Tungsten, 1200VA Ballast |
||
Rated Loading (-HP) |
1800W Tungsten, 1800VA Ballast |
||
Power Consumption |
1.5VA (3.0VA for -HP) |
||
On/Off Level |
10~20Lx On 30~60Lx Off |
||
Ambient Temp. |
-40°C ~ +70°C |
||
Related Humidity |
99% |
||
Overall Size |
84(Dia.) x 66mm |
||
Weight Approx. |
85~110 grs |
||
