photocell
The photocontroller JL-207 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.
This product is designed with electronic circuits with sensor of photodiode and a surge arrester (MOV) is provided. Its quicker response with time delay of 3-5 seconds offers easy-to-test feature. Especially, model JL-207C provides a wide voltage range for customer applications under almost power supplies.
JL-207 offers the mid-night turning-off feature for saving more energy. After about 6 hours turned on the loading lamp, it switches off the lamp until the next dusk. Further, a preset 3-5 seconds time-delay might avoid mis-operation due to spotlight or lightning during the night time.
This product provides twist lock terminals meeting the requirements of ANSI C136.10-1996 and the Standard for Plug-In, Locking Type Photocontrols for Use with Area Lighting UL773, 4th Edition, dated Jan.19th, 1995,
Model |
JL-207A |
JL-207B |
JL-207C |
Rated Voltage |
110-120VAC |
220~240VAC |
110-277VAC |
Applicable Voltage Range |
100-140VAC |
200~260VAC |
105-305VAC |
Rated Frequency |
50/60Hz |
||
Rated Loading |
1000W Tungsten, 1800VA Ballast |
||
Power Consumption |
1.5VA |
||
On/Off Level |
6Lx On 50Lx Off |
||
Ambient Temp. |
-40°C ~ +70°C |
||
Related Humidity |
99% |
||
Overall Size |
84(Dia.) x 66mm |
||
Weight Approx. |
85 grs |
||
