SZ-350D Computer Dual Frequency Conversion Control

FOB Price

US$ 3,700 - 5,700 / Set

1 Set(Min. Order)

Port Foshan
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Function	Wrapping
Application	Food, Commodity, Medical, Chemical, Other, Apparel, Textiles, Food, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles	Packaging Type	Bags, Film, Foil, Belt, Pouch, Capsule, Other, Bags, Film, Foil, Belt, Pouch, Capsule, package
Packaging Material	Plastic	Automatic Grade	Automatic
Driven Type	Electric	Voltage	220V
Power	2.6W	Place of Origin	Guangdong, China
Brand Name	SUK	Model Number	SZ-350D
Dimension(LWH)	4020x770x1410	Certification	CE
After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

1/ Simple Opearation;
2/ Easy Maintenance;
3/ Durable;
4/ Efficient Follow-up Serivce

FOSHAN SUK Packing Machinery Co.,Ltd is a professional packaging machine manufacturer with 5 years' experience in China. We offer over 18 various kinds of packaging machines and our monthly output amounts to more 100 sets. We will supply you a high quality packing machine and a resonable price .Hoping to be your reliable parter in China.

Packing material: Heat-sealable laminated film, such as: OPP,PE,PVC,PT/PE,OPP/CPP ,other special sealable packing film.

Sealing Type: Back-sealed (3 sides sealed)

SZ-350D Computer Dual Frequency Conversion Control

I. Main performance and structure features

1. Double transducer control, flexible bag length cutting, operator needn’t to adjust the unloading working, saving time and saving films.

2. human-machine operation, convenient and quick parameter setting.

3.Self diagnosis failure function, clear failure display.

4. High sensitivity optical electric color mark tracking ,digital input cut position which makes the sealing and cutting more accurate.

5. Separate PID control to temperature, suitable for various packing materials.

6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.

7. Simple driving system, reliable working, convenient maintenance.

8. .All the controls are achieved by software, convenient for function adjusting and upgrading.

II. Application

Suitable for packing regular objects such as biscuit, bread, instant noodle, moon cakes, industrial parts, paper box or trays.

III. Optional device

1. Code applying machine

2. Extra big screen

IV. Specification:

Type	SZ-350B	SZ350D		SZ-400B	SZ-400D
Film width	Max.350mm			Max.400mm
Bag length	65-190/120-280mm		90-220/150-330mm	130-320mm	180-400mm
Bag width	50-160mm			50-185mm
Product height	Max.40mm	Max.60mm		Max.40mm		Max.60mm
Film roll diameter	Max.320mm
Packaging rate	40-230bag/min			30-180bag/min
Power	220v 50/60Hz 2.6KW
Machine size	(L)4020×(W)770×(H)1450mm			(L)4020×(W)800×(H)1450mm
Machine weight	800kg			900 kg
Remarks	Optional air filling device

V. Electric detailed list:

No.	Product Name	Brand
1	PLC	Panasonic/Japan
2	INVERTER	Schneider
3	7 inchTouch screen	Wei Lun/Taiwan
4	Intermediate Relay	OMRON
5	Switching power	Meanwell/Taiwan
6	solid state relay	Schneider
7	Temperature controller	Yatai/Shanghai
8	Photoelectricity colour code	Aiset

Machine pictrues:

Workshop:

Effect of packing :
