China manufacturer,High speed plastic film PE OPP PP roll four colours flexo printing machine
)Ink :Adopt the automatic circle system ,running ink by single small motor ,with the electrical clutch device
2)Timing :Adopt Japanese inverter controlled ,running by small fluctuations
3)Unwinding EPC :adopt the high quality automatic EPC controller device
4)Unwinding and rewinding method : adopt the magnetism Auto tension controller
5)Ink way :our company has special design for the doctor blade device with the ink pump can suck the ink automatically
6)Up and down plate :adopt the hydraulic pressure rising and down the printing plate automatically
Pringting width Item |
600mm |
800mm |
1000mm |
1200mm |
1400mm |
1600mm |
1800mm |
2000mm |
Printing color |
4 color/colors ( PC : 4+0 , 3+1 , 2+2, 1+4) |
|||||||
Printing material |
LDPE : 28 - 100μm LDPE : 30 - 100μm LLDPE : 25 -100μm CPP : 20 -60mic PP : 23 - 65mic NY : 20 - 50mic PETP : 16 ~ 60mic OPP : 18 -70mic |
|||||||
Printing length |
7.5 ″ -40 ″ /7.5 ″ -50 ″ /7.5 ″ -60 ″ /7.5 ″ -70 ″ /7.5 ″ -80 ″ |
|||||||
Printing plate lifting system |
Pneumatic/Hydraulic press control/Menu |
|||||||
Mechanical speed |
90m /min |
|||||||
Printing speed |
70m /min |
|||||||
Anilox cylinder |
Metal : 10DK-120DK( Germany )/200-500LPI( Japan ) |
|||||||
Register precision |
Longitude: ± 0.15mm , Transverse: ± 0.15mm |
|||||||
Rewinder/Unwinder DIA |
φ 600 |
|||||||
Master motor |
3.7kw |
3.7kw |
5.5kw |
5.5kw |
7.5kw |
7.5kw |
11kw |
11kw |
unwinding motor |
1.1kw |
1.5kw |
2.2kw |
3.0kw |
||||
rewinding motor |
1.5kw |
2.2kw |
3.0kw |
3.7kw |
||||
Electrical heater |
14kw |
16kw |
20kw |
22kw |
24kw |
26kw |
28kw |
30kw |
Blower of heater |
1.5kw x2 |
1.1kw x3 |
1.1kw x3 |
1.1kw x3 |
1.5kw x3 |
1.5kw x3 |
2.2kw x3 |
2.2kw x3 |
Blower of nature wind |
0.75KW |
0.75KW |
1.1KW |
1.1KW |
1.1KW |
1.5KW |
1.5KW |
1.5KW |
Inking motor |
750w |
750w |
750w |
750w |
750w |
750w |
750w |
750w |
Bearing |
Japan ( NSK) |
|||||||
Unilateral bearing |
ASNU( Germany ) |
|||||||
NET Weight |
4500kg |
4750kg |
5000kg |
5250kg |
5500kg |
5750kg |
6000kg |
6300kg |
Master Power |
25kw |
27kw |
34kw |
37kw |
43kw |
47kw |
55kw |
58kw |
