Home > Products > Plastic pipe machine > 16~750mm PVC PE PP Pipe Plastic Machine Line/ Tube Extruder
16~750mm PVC PE PP Pipe Plastic Machine Line/ Tube Extruder
- Xingang
- T/T
You May Like
Product Details
| Condition | New | Application | Pipe | |
| Plastic Processed | Other, PE/PVC/PP | Screw Design | Single-screw | |
| Automatic Grade | high automatic | Place of Origin | Hebei, China | |
| Brand Name | ZFSJ | Model Number | SJ-70 | |
| Voltage | 380V | Power(W) | 85kw | |
| Dimension(L*W*H) | 15.8M*2.3M*2.8M | Weight | 3T | |
| Certification | CE,ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
16-750mm PVC PE PP pipe plastic machine line/ tube extruder
Characters of the machine
The extruder adopts frequency converter control which has the features of easy adjustment, reliable running, stable working and low energy consumption. It adopts independent electirc cabinet and it is easy for the whole machine's centralized control and operation.
The screw bolt and barrel of the extruder is made of good quality nitriding steel. The design is reasonable and the plasticizing effect is excellent and it features stable production.
Shaping of the pipe adopts center material feeding mold and vacuum sizing. Cooling method is the combination of spraying and leach so the precision of the pipe will not deform easily due to plasticity.
It adopts special-purpose roller type tractor and the pipe will not deform easily due to plasticity.
Soft pipe rolling machine adopts torque motor control which overcomes disadvantage of tension. It adopts independent electric cabinet control which is convenient for independent control and operation during production.
When producting small diameter pipe change winder to coiler for hard pipe and equip the line with suitable extruding mold, hard pipe can be produced. When producing big diameter pipe, it shall adopt caterpillar type tractor and change winder to pipe rack and equipped with suitable extruding mold and pipe cutting device to produce hard pipe.
Main technical parameter
| Parameter | Technical Parameter | |||
| Model | SJ-45 | SJ-65 | SJ-90 | |
| Max. extruding capacity | 40kg/h | 60kg/h | 100kg/h | |
| Main driving power | 15kw | 22kw | 37kw | |
| Filter changing method | Durable filter | Durable filter | Durable filter | |
| Heating power | 15kw | 22kw | 37kw | |
| Sizing way | Vacuum sizing | Vacuum sizing | Vacuum sizing | |
| Pipe specification | Diameter:16-40mm | Diameter:20-75mm | Diameter:63-160mm | |
| Cooling way | Spray+immersion | Spray+immersion | Spray+immersion | |
| Tracting type | Roller type tractor | Roller type tractor | Roller/caterpillar band type(for hard pipe) | |
| Tractor driving power | 1.5kw | 2.2kw | 4kw | |
| Winding motor | 6N*m | 6N*m | 12N*m | |
| Installation power | 40kw | 50kw | 85kw | |
| Overall dimension | Soft pipe | 12m*1.6m*2.6m | 12.2m*1.6m*2.7m | 15.8m*2.3m*2.8m |
| Hard pipe | 15m*3m*2.6m | 16.5m*3m*2.7m | 21m*2.3m*2.8m | |
Plastic pipe making machine
Certificate/Patent
| Item | Certificates/patent type |
| Durable filter | Utility new type patent |

Port: Xingang
Package: standard export sea-worthy wooden box, one 20ft container



Brief Introduction
Tangshan Zhifu Plastic Machinery Co., Ltd was established in 1986,which lies in the southeast of Beijing (capital of China) It covers more than 50000m2 area.
It is a knowledge-based, scientific and technological enterprise for special-purpose plastic machinery integrating design, develop, manufacture and service with advanced equipment, perfect monitoring method and strong technological foundation.
Our General manager has been received by Mr Hu president twice. T
The company has import-export authority independently and passes the Certificate of ISO9001 Quality System and European Union CE Certificate.
Our company which has more than ten years of history for making drip irrigation equipment in China and even the biggest drip irrigation machine manufacturer and sale enterprise in the world.
The superior quality, favorable price and perfect after-sales service make the products be well received at home and abroad.
The management principle of our company is sincere cooperation and deep friendship, and our service aim is Quality First and Credit First and Customer First to meet the customer’s demand and expectation. We are devoted to the improvement of the product quality and service and try our best to provide the best quality product to friends from all over the world.
