Application:
It is widely used in lawn, trees, greenhouse and so on.
Picture of machine:
Main technical parameter:
No. |
Item |
Technical parameter |
1 |
Model |
SJWP-60 |
2 |
Specification |
Φ25-Φ75 |
3 |
Screw diameter |
Φ60mm |
4 |
Main driving power |
18.5kw |
3 |
Max.extruding capacity |
50kg/h |
4 |
Filter changing way |
Durable filter |
5 |
Traction motor |
1.5kw |
6 |
Winding motor |
0.75kw*2 sets |
7 |
Installation power |
48kw |
8 |
Production speed |
≤35m/min |
9 |
Overall dimension(L*W*H) |
11m*2.25m*3.6m |
Note: 1).production speed can be 30m/min
2). It can print, but you need to pay extra 600USD
Features of machine:
1). Extruder and tractor all adopt frequency conversion control system, which has the characteristics of easy operation, reliable running, stable working and low energy consumption.
2). Screw bolt of the extruder adopts special design, and its features excellent plasticating capacity and stable production.
3). Extruder and mold adopt automatic temperature control system so that the temperature-controlling is exact and also it can save energy effectively.
4). Unique vacuum control device, precise vacuum degree control, small micro-spraying tape diameter error.
5). Space control device adopts servo motor control, control accuracy is high, position error is small.
6). Punch on the hole drilling machine is made of special steel and it has long service life.
7). Hole drilling machine adopts advanced servo unit control, human-computure interface operation, punching accuracy is high, water outlet space error is small, high degree of automation.
8). Double-station winder make changing roll is convenient and quick, and equip the meter-counting device, rolling length can be settled by self(≤200m), after reaching setting length, it will be alarming.
Packaging and Shipping:
1). Packaging: wooden box, 20 feet container.
2). Delivery period: 40 working days
3). Transportation way: by sea
4). Shipping port: XINGANG, CHINA
Technical parameter by this machine:
Sizes |
Thickness (mm) |
Holes space (mm) |
Holes type |
Working pressure (Mpa) |
Paving width (m) |
Spraying width (m) |
Each roll length(m) |
|
|
Diameter (mm) |
Folded diameter (mm) |
|||||||
Φ25 |
39 |
0.2 |
≥150 |
Two holes |
0.1 |
≤50 |
≤2 |
200 |
0.3 |
≥150 |
Two holes |
0.1, 0.2 |
≤80 |
≤3 |
150 |
||
0.4 |
≥150 |
Two holes |
0.1, 0.2 |
≤80 |
≤3 |
100 |
||
Φ32 |
50 |
0.2 |
≥150 |
Sloping three holes |
0.1 |
≤60 |
≤3 |
200 |
0.3 |
≥150 |
Sloping three holes |
0.1,0.2 |
≤80 |
≤5 |
150 |
||
0.4 |
≥150 |
Sloping three holes |
0.1,0.2 |
≤80 |
≤5 |
100 |
||
Φ40 |
63 |
0.2 |
≥150 |
Sloping three holes |
0.1 |
≤60 |
≤3 |
200 |
0.3 |
≥150 |
Sloping three holes |
0.1, 0.2 |
≤80 |
≤5 |
150 |
||
0.4 |
≥150 |
Sloping three holes |
0.1, 0.2 |
≤80 |
≤5 |
100 |
||
Φ50 |
78.5 |
0.2 |
≥150 |
Sloping five holes |
0.1 |
≤60 |
≤5 |
200 |
0.3 |
≥150 |
Sloping five holes |
0.1, 0.2 |
≤80 |
≤7 |
150 |
||
0.4 |
≥150 |
Sloping five holes |
0.1, 0.2 |
≤80 |
≤7 |
100 |
||
Φ63 |
99 |
0.2 |
≥150 |
Sloping five holes |
0.1 |
≤60 |
≤5 |
200 |
0.3 |
≥150 |
Sloping five holes |
0.1, 0.2 |
≤80 |
≤7 |
150 |
||
0.4 |
≥150 |
Sloping five holes |
0.1, 0.2 |
≤80 |
≤7 |
100 |
||
Φ75 |
118 |
0.2 |
≥150 |
Sloping seven holes |
0.1 |
≤60 |
≤6 |
200 |
0.3 |
≥150 |
Sloping seven holes |
0.1,0.2 |
≤80 |
≤8 |
150 |
||
0.4 |
≥150 |
Sloping seven holes |
0.1, 0.2 |
≤80 |
≤8 |
100 |
||
Note: You can choose four specification from Φ25-Φ75 with one machine for free. But if you choose more than four or not within Φ25-Φ75, you need to pay.
About the order of the machine:
Minmum order quantity of machine: one set
Delivery period: 40 working days
1). What’s your patment term?
T/T, L/C(you must pay 30% of total contract amount by T/T as deposit.).
2). Can I get a sample? And how?
Yes, you can get some sample, and you need to pay for it. However, that cost can be refundable after you buy our machines or tapes more than MOQ.
3). What kind of files do you accept for printing?
PDF, Word, PPT, High resolution JPG.
4). Can you do the design for us?
Yes,just tell us your ideas and we will help to carry out your ideas into perfect products.
5). What about the lead time for mass production?
Honestly,it depends on the order quantity and the season you place the order.The lead time of MOQ is about 10 to 15 days. Generally speaking,we suggest that you start inquiry one month
before the date you would like to get the products at your country.
6). How long is your guarantee?
One year (Calculated from the equipment arrives at the customer’s side.).
Why choose us:
| Professional | with 10 years profesional manufacturing experience |
| Profesinal production line,well -trained workers | |
| Main market | Our products have shipped around the world |
| Norway, Denmark, Sweden, Germany, Australia, USA, Brazil etc | |
| Service | We have good and professional team |
| We accept any drawings or your samples to develop new product | |
| Any small problems will be solved at the most prompt time | |
|
We always offer relateive technical support, quick response,all your inquire will replied within 24 hours |
>>>Company profile
1). Main products:
Single blade labyrinth drip irrigation machine
Melt-flow type drip irrigation machine
Inline flat drip irrigation machine
Inline column drip irrigation machine
Injection machine
2).Address:Tangshan Zhifu Plastic Machinery Co., Ltd. established in 1986, lies to 110kmsout heast of Beijing(capital of China).
3).Aim:Fulfilling customer’s requirement is the only mission of the company, satisfying customer’s expectation is our everlasting pursuit.
4).Customers: Europe, Americas, Middle East, and Southeast Asia etc.
5).Employees: more than 200 people.(including 30 engineers)
>>>Manufacture and Workshop
>>>Certification
Our company has import-export authority independently and passes the Certificate of ISO9001 Quality System and European Union CE Certificate.
>>>Exhibition
Service:
1. We are willing to assist to install and test machine, transfer the technique, train the staff and provide maintenance support.
2. We can provide free sample for your check.
3. We are willing to provide design and turn-key project according to client’s request.
whatsapp: 86 15031876882 (I will be here waiting for you)
