EPHC-ST Solar Home System Controller Regulator, 12 VOLT or 12/24 VOLT Auto Work, 10 AMPS (for PV and Load)

EPHC-ST Solar Home System Controller Regulator, 12 VOLT or 12/24 VOLT Auto Work, 10 AMPS (for PV and Load) thumbnail-1
EPHC-ST Solar Home System Controller Regulator, 12 VOLT or 12/24 VOLT Auto Work, 10 AMPS (for PV and Load) photo-1
Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
linquan
Model Number:
EPHC-ST
Contact Supplier Request Quote Chat Now
Jinan Linquan Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name linquan
Model Number EPHC-ST
Application Solar System Controller
Rated Voltage Other, 12V/24V auto work
Maximum Current 10A

Specifications

EPHC-ST Solar Home System Controller Regulator
Microcontroller digital accuracy
External temperature sensor
PWM Charge mode



EPHC-ST Solar Home System Controller Regulator





EPHC-ST
SOLAR CONTROLLER FOR SOLAR HOME SYSTEMS
EPHC-ST series is the second generation of small solar controller.
It is ideal for rural electrification. PV system.
Features
Microcontroller digital accuracy
PWM Charge mode
State of charge (SOC)
Temperature compensation
Automatic detection of the voltage
External temperature sensor
Big terminals and big distance between terminals
Electronic protection
Short circuit protection
Reverse polarity protection
Reverse current protection at night
Over charging or discharging protection
Display
3 LED indicators
PV: Green -charging
Battery: Green-Yellow-Red
Load: Red -low voltage warning and disconnect
LED blinking shows mistakes
Technical specification

EPHC-ST series:

12 VOLT or 12/24 VOLT auto work, 10 AMPS (for PV and load)

Equalization voltage:  14.8 Volt
Boost voltage:  14.4 Volt
Float voltage:  13.6 Volt
Low voltage disconnect (LVD)  11.10 Volt
Low voltages reconnect (LVR):  13.1Volt
Temperature compensation:  -30mv/°C/12V
Self-consumption:  6mA maximum
Terminals:  for wire sizes to 6 mm2
Temperature:  -35°C to +55°C
Notes: It is for 12V system. Please X2 for 24V system.
WARRANTY: One year warranty period.









Jinan Linquan Industry and Trade Group Co., Ltd
LQTRADE SERVE THE WORLD



EPHC-ST Solar Home System Controller Regulator, 12 VOLT or 12/24 VOLT auto work, 10 AMPS (for PV and load)
