Specifications
High speedPLC control system
Competitive price
CD-150 LOG SAW toilet rolls machine is one of the important equipment for the automatically
continuous production line of toilet rolls and kitchen towels, greatly increasing the production
automation and efficiency. The machine is characteristic of a strong, well built structure and
perfect cutting action. 1.Function and feature Automatic blade sharpening unit complete with
lubrication system. Log accompaniment system. Automatic trim eliminating device.
Automatic approach of grinding wheels to cutting blade based on the blade wear.
Two clamping systems for toilet rolls and kitchen towels. Short change over time.
Option: can also be the log saw for facial tissue, which is the model will be different.
Main Technical Parameter of the log saw:
l Log length: 1500mm~2700mm
l Log outside diameter: 90mm~150mm (standard size: 110±5mm)
l Cutting length: variable
l Machine speed: 160cuts/min, 2 rolls /cut
l Operation speed: 150cuts/min, 2 rolls /cut
l Blade outside diameter: 610mm
l Installed power: Alternating Current: 5 Horses per Machine
l Frequency Conversion: 5 Horses per Machine
l Alternating Current: 1/2 Horses per Machine, AC motor 5 Horses
l Machine size: 5730*1720*1920mm (L*W*H)
Main features
l Automatic blade sharpening unit, complete with lubrication system.
l Automatic rewinding paper roll by machine into paper cutter to cut off. Then aromatically send out.
l Automatic trim eliminating device.
l Two clamping system fro toilet rolls and kitchen towels.
l Change the clamping system commodiously and time-saving.
l Clip paper channel mold outside diameter size can be customized according to the customers’ demand.
