Help CenterCDH-1575 YE Toilet Paper Slitting Rewinder
Related Products
Specifications
1.For toilet paper roll making2.High speed
3.Embossing unit and color printing can be customized
4.stable running,good price
CDH-1575 YE Toilet Paper Slitting Rewinder
Detailed Product Description
Automatic Trimming, Sealing, Embossing and Perforating Rewinder adopt advanced PLC technology, variable speed adjustment, electronic braking, and touch button
multimenu type LCD screen operation control panel. Also the machine is newly added coreless roller shaped rewinding system. It’s adopt PLC wind pipe-shaped new technology. It’s no need to put core or stainless steel pipe. It’s full upgrade the whole machine.
Function and features:
1.Automatic paper tube replacement device,do not need artificial wear paper tube,
and then finish rewinding and sent out the finished products,immediately letters forrewinding,can adjust at will within one minute any kind of paper tube specifications
2.Automatic trimming ,spray adhesive and sealing a complete synchronization,finished with 10-18mm paper tail,convenient opening ,reduce the wastage ordinary
paper rewinding mechanism make the tail,and thus reduce the product cost.
3.With advance PLC programming techniques,Fault screen display,man-machine
interaction parameters.
4.High precision screw soft knife,3 knife punching low noise,punch more clear,gearbox the adjusting range is large.
5.Three layers of horizontal paper back frame,pneumatic on paper ,pneumatic wide belt to sent paper,each roll of base paper were independent adjustment device.
Main Technical Parameter | |
Finished product |
Only for toilet paper roll |
Finished Roll Diameter |
Φ60~150 mm (Degree of tightness adjustable) |
Finished Roll Core Diameter |
Φ 32~50 mm |
Raw Material Diameter |
≤Φ 1100 mm (Other sizes are available ) |
Raw Material Core Diameter |
3”(76.2 mm) (Other sizes are available ) |
Perforating Pitch |
90~160mm (Pneumatically separating unit-Optional) |
Speed |
180-200 meters/min |
Parameter Setting |
Touch button LCD Screen operation panel |
Programme Controller |
Delta Programmable Controller (PLC) |
Mechanism Driving |
Stepless gear box, insure the precision of finished product length |
Embossing Roller |
Two sets of Steel to rubber |
Lamination |
Without lamination |
Color |
Without color printing |
Unwinding Paper Stand |
1-3 ply |
Power |
Variable frequency speed control, 9KW 380V 50HZ |
Machine Size |
6200×4200×1800mm(L×W×H) |
Weight |
6800kg |
|
Pneumatic System 3 HP air compressor, mini pressure 5kg/cm2 Pa(Provided by client) | |
