Help CenterCDH-1575 YQ Full Automatic Toilet Paper Production Line
Related Products
Specifications
1.For toilet paper making2.,with log saw and packing part
3.high speed
4.Good quality
5.good after service
Part 1:
Detailed Product Description
1.It cis only for for the toilet paper . The punching size can be adjustable.
2.Two sets of steel to rubber embossing units
3.Automatic core loading and replacing.the logs are automatically pushed out after finishing winding, and then start winding again. The cores can be adjusted to any
size of cores within one minute.
4.Automatic trimming, gluing and sealing: it has replaced the traditional sealing of rolls with the international popular trimming and sealing,which can have 10-18mm
tails to facilitate to start pulling out the paper. At the same time, it can greatly
cut down the wastage of the paper,thus to cut down the production cost.
5.Advanced PLC programmable control Technology: The winding profiles can be
tight at the beginning of winding, and then getting loose,to avoid the problems
that the cores are loose from the rolls after long time storage.
6.With high precision screwy perforation knife.with 4 performation blades to make
clear perforating. The perforating pitch controlled by gear box
7.Two backstands,pneumatic jumbo roll loading,and pneumatically wide belt paper unwinding driving, and individual web tension control unit for each jumbo roll.
Main Technical Parameter | |
width of Jumbo Roll |
1750mm |
Diameter of Jumbo roll |
1100mm |
|
Inner diameter paper core of Jumbo roll |
76.2mm |
Diameter rewinding product |
60-150mm |
|
Inner diameter paper core of rewinding product |
32-50mm |
Punching size |
10-15mm |
Working speed |
120-160m/min |
Setting Parameter |
Interaction |
Color printing |
without |
lamination |
without |
Pneumatic |
3HP ,Above 5kg/cm2 Pa |
Install power |
7.5-15KW |
Back paper stand |
2 or 3 pieces |
Part 2:
Low saw is one of the important equipment for the automatically continuous
production line of toilet rolls ,greatly increasing the production automation and
efficiency.the machine is characteristic of a strong,well built structure and
perfect cutting action.the machine is equipped with the following:
Ⅰ. Main feature:
1.Automatic blade sharpening unit complete with lubrication system
2.Automatic approach of grinding wheels to cutting blade based on the blade wear
3.Log accompaniment system
4.Automatic trim eliminating device
Main Technical Parameter | |
Log Length |
1750mm |
Log outside diameter |
105-115mm |
Cutting length |
Customize(above 6mm) |
Diameter of round blade |
610mm |
Speed |
70-80 cut/min |
Install power |
11KW |
Machine dimension |
5730X1720X1920 |
weight |
about 3.5Ton |
Part 3 (Packing) :
It will automatically group the rolls and transfer them into the bags,on
configuration of 6,8,10,12,16 and 20 rolls per bag, on one layer or two layers,core
or standing up type,with one automatic sealing machine to seal the packages
coming out from the bagger.This bagger can be run only by one person.
