CDH-1575 -GS Kitchen Paper Machine

Name: CDH-1575 -GS Kitchen Paper Machine
Brand: Chuangda
SKU: 126562619
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Product Type:

Other, kitchen paper making machine

Processing Type:

Other, kitchen paper making machine

Chuangda Machinery (Fujian) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XIAMEN PORT CHINA

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Product Type Other, kitchen paper making machine

Processing Type Other, kitchen paper making machine

Place of Origin Fujian, China

Brand Name Chuangda

Model Number CDH-1575-GS

Voltage 380V 50HZ

Power(W) 32KW

Dimension(L*W*H) 9500*3100*2200 mm(L*W*H)

Weight 12000kg

Certification CE

Warranty within one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.For kitchen paper or toilet paper roll making
2.High speed
3.Color glue lamination unit
4.Tension control
5.good price

CDH-1575 -GS

Full Automatic Kitchen Paper Machine

Main Feature:

1.Automatic tension control system, base paper independent frequency conversion motor drive, adapted to different traction base paper

2.Bigger steel embossing roller make embossing clear,Polyurethane embossing roller with good elasticity,long service life

3.Unique gluing composite system, it can produce finished product with color glue,part ofgrain with color.

4.Four pieces of High precision spiral perforated knife roller, the lineup is clear,easy to tear,with low noise

5.Special Suede belt drive system,Adjustment Convenient ,Tightness of the finishedproduct is adjustable

6.Using wallboard structure,make it with Strong rigidity and high stability,

prolong the machine service life

Main Technical Parameter
Electric source	380V, 50Hz, 3 PH
Finished Roll Diameter	90-150mm
Finished Roll Core Diameter	Φ 48 mm
Raw Material Diameter	≤Φ 1100 mm (Other sizes can be customized)
Raw Material Core Diameter	3”(76.2 mm) (Other sizes are available )
Width Of Raw Material	1750mm, only for producing kitchen paper roll
GSM of raw paper	19-25g
Perforating Pitch	105~160mm
Speed	120-150 meters/min
Parameter Setting	Touch button LCD Screen operation panel
Program Controller	Programmable Controller (PLC)
Mechanism Driving	synchronous belt drive
Embossing Roller	Polyurethane embossing roller
Embossing type	Point to point
Color unit	Without color printing
Lamination unit	With lamination
accumulator	One set
accumulator	40 pieces shelves which can be store 20 pieces of finished roll
Unwinding Paper Stand	2
Power	Variable frequency speed control, 32KW
Machine Size	950031002200mm(LWH)
Weight	12000kg
