Specifications
automatic tablet press machine:1) High quality.
2) Factory sale with 30 years' producing experience.
3) Reliable service.
China manufacturer shisha/hookah tablets briquette automatic tablet press machine
Our automatic tablet press machine:
Shisha charcoal tablets made by automatic tablet press machine:
Brief description of automatic tablet press machine:
Automatic tablet press machine is mainly used in charcoal powder, pharmaceutical,
food, chemical industries. Automatic tablet press machine is designed according to
GMP standard, whose appearance is stainless steel packing. The tablet press of
automatic tablet press machine is small in size and neat appearance. Besides,
automatic tablet press machine also has the security alarm system, dust collection
system. Automatic tablet press machine’s rotation uses stepless speed regulation of
frequency conversion. Automatic tablet press machine is used to press charcoal
powder into certain small shape.
The pressure made by automatic tablet press machine can be reach at 20Mpa, the
speed of automatic tablet press machine is adjustable according to your demands.
Visitors came to test automatic tablet press machine:
For automatic tablet press machine's final products-- Shisha charcoal tablets
1) automatic tablet press machine can press charcoal/coal powder material into
various shapes. The shapeand sizes of shisha charcoal tablets can be cube (25
*25*25 mm, 20*25*25 mm, 10*10*10 mm), round (diameter: 28 mm, 30 mm, 32
mm, 35 mm), we can make the mold according to customers' requirements.
2) The final products made by automatic tablet press machine are smoke-free,
tasteless, non-toxic, flammable.What’s more, the output shisha charcoal tablets
in good density, perfect shape and good appearance.
Main parameter of automatic tablet press machine:
Type |
YPJ-11 |
YPJ-28 |
Capacity |
11-12pieces/time |
28pieces/time |
20-22times/min |
3-5times/time |
|
Motor |
7.5kw(4pole) |
11kw(4pole) |
Diameter of briquettes |
20,25,30,33,35,38,40,43mm(round)20-24mm(cubic) |
20,25,30,33,35,38,40,43mm(round)20-24mm(cubic) |
Feeding materials |
<3mm |
<3mm |
Briquette shape |
round,square,triangle(as customer’s request) |
round,square,triangle(as customer’s request) |
Pressure |
30-80tons |
50-100tons |
Press type |
Mechanical Press |
Hydraulic Press |
Overall Size |
2500*950*1550mm(includes conveyor) |
3500*2000*1800mm(includes conveyor) |
Packing Size |
1500*1200*1750mm |
2100*2100*1900mm |
Weight |
1500kg |
1800kg |
The whole production line of automatic tablet press machine:
Our new design hydraulic automatic tablet press machine:
Compared with technical automatic tablet press machine, hydraulic automatic tablet press
machine has much more tremendous pressure, much larger capacity, much more stable
running process. The shisha charcoal tablets made by hydraulic automatic tablet press
machine are in high density. The pressure can be reach 50Mpa. Shisha charcoal tablets'
height can be in 10-70mm.
Other assistant equipments of automatic tablet press machine:
1) Charcoal crusher: the first step of automatic tablet press machine is to crush raw
material into fine charcoal powder. The smaller the charcoal powder's size is, the better.
(automatic tablet press machine)
2) Mixer: The second step of automatic tablet press machine is to mix charcoal powder
with natural binder evenly. The reason why we use wheel mixer is that wheel mixer can not
only improve charcoal powder's density, but also press charcoal powder into smaller size.
(automatic tablet press machine)
3) Box dryer: The last step of automatic tablet press briquette machine is to dry up shisha
charcoal tablets in box dryer. Due to the liquid binder, shisha charcoal tablets will have
15-20% water content, so we need to dry the briquette.(automatic tablet press machine)
If you are interested in our automatic tablet press machine or the whole
line of automatic tablet press machine, please contact me freely!
Skype: amy.tangcn
TEL: 0086-155 1616 6281
QQ:1083911070
Other kinds automatic charcoal briquette machine:
(please click the following picture, then you will see other kinds automatic charcoal briquette
machine)
Lantian Mechanical Plant:
Lantian Mechanical Plant is a professional factory in producing coal/charcoal briquettes
machine and any other assistant equipments of briquette machine. Our factory was
founded in 1980s. and through 30 years' development, our machines have earned
good repulation in China, but also in foreign countries. Our main briquette machine
includes automatic coal briquette machine, automatic shisha tablet press machine,
automatic roller press coal/charcoal briquette machine, crusher, mixer, dryer,
conveyor, etc. (automatic tablet press machine)
