Specifications
clc brick making machine:1) 30 years' development
2) 6 years' export experience
3) reliable service
Factory direct sale high quality clc brick making machine
Lantian Mechanical Plant
Lantian Mechanical Plant was founded in 1980s. It is a professional brick machine making factory since
1980s.Through 30 years' development, our factory has been specialized in brick machine area over 30
years. Our brick making machine includes clay brick making machine, mud brick making machine, ash
brick making machine, etc. Apart from all kinds of brick making machine, our factory also produce other
assistant equipments, such as brick cutter, brick stacker, mixer, feeder, etc.(clc brick making machine)
Part one: what's clc brick making machine?
Clc brick making machine is suitable for shale, coal gangue, clay and other raw materials to produce all
kinds of hollow brick, standard clay brick. Clc brick making machine addopts upper and lower structure.
The upper and lower transmission adopts ZQ type national standard reducer, the axial pneumatic clutch,
and the whole engine is totally welded by steel plate. The surface og the rimer uses wear-resisting material
spray welding process to prolong its service time. (clc brick making machine)
Part two: clc brick making machine show
Part Three: Characteristics of clc brick making machine
1. For doubles shaft mixer blades, we choose 45 Carbon steel.
2. For roller crusher ,we use high manganese
3. Steel axles, gear and other important spare parts which are made by carbon steel and alloy steel through
modulation or quench’s heat treatment procession so as to extend the service life.
4. Compact structure.
5. Strong practicability, small investment, quick effect.(clc brick making machine)
Part four: Different bricks made by clc brick making machine
Part five: clc brick making machine production line
Clc brick making machine production line includes box feeder→ Roller crusher/ Jaw crusher→Double shaft
mixer→ Finess crusher→ Extrudering mixer →Clc brick making machine → Brick slitter→ Brick cutter→
Brick Stacker→Kiln Car → Kiln.(clc brick making machine)
1. Raw material & fuel preparation and handling
1)Send clay raw material to box feeder with loader. Send the clay raw material to double-roll crusher for
preliminary crushing .
2)Preliminary crushed material is conveyed to twin-shaft mixing machine for adding water and agitating
through belt conveyer.
3)After mixing of the first working procedure, the raw material is again sent to intense agitation extruder
and high speed fine pulverizing double roll grinder for supplement water and agitating the raw material.
(clc brick making machine)
2. Molding
1)The molding water content rate should be controlled within 16%-18%.
2)The vacuum pump will take out the air that entered into the extruding machine together with pug. The
clc brick making machine will extrude the pug from machine mouth and then, carry out slitting & parting
according to the required dimension.(clc brick making machine)
3. Drying
1)When the unfired bricks cut by cutter and arranged into groups.
2) The drying chamber work system has heating system, regulating system and moisture excluding system.
The drying quality is controlled by regulating system. clay brick machine.(clc brick making machine)
4. Burning
1)After drying , the unfired bricks are sent onto kiln by the dried brick cart,stacking bricks onto the kiln car
for burning.
2)unloading system The properly burned bricks.(clc brick making machine)
Part Six: Main parameter of clc brick making machine
Type |
Diameter of reamer of extruding end (mm) |
Capacity (pieces(standard brick size)/h) |
Authorized pressure(Mpa) |
Vacuum Degree(Mpa) |
Installed capacity(kw) |
Dimension(mm) |
JKY70/70-2.5 |
700 |
19000~24500 |
2.5 |
-0.092 |
250+90+1.5 |
6687×6765×2846 |
JKY70/60-3.8 |
600 |
14000~15000 |
3.8 |
-0.092 |
250+90+2.2 |
6632×6855×2866 |
JKY60/60-4.0 |
600 |
21000~24480 |
4.0 |
-0.092 |
250+90+7.5+1.5 |
4819×6416×3065 |
JKY60/50-4.0 |
500 |
12000~18000 |
4.0 |
-0.092 |
200+75+1.5 |
5844×6102×2796 |
JKY50/50-4.0 |
500 |
12200~13420 |
4.0 |
-0.092 |
200+90+7.5+1.5 |
6904×5352×2820 |
JKB50/45-3.0 |
450 |
9800~15100 |
3.0 |
-0.092 |
132+55 |
5375×4521×2723 |
JKR50/45-2.0 |
450 |
12000~16000 |
2.0 |
-0.092 |
110+55 |
4900×4204×2723 |
Part Seven: Installation of clc brick making machine
1) Clc brick making machine should be installed in a horizontal concrete, fixed by foundation bolt.
2) Clc brick making machine's main body should be located vertically with ground.
3) After clc brick making machine and its assistant equipments being installed, we should check
each part, each bolt, host storehouse door to see whether ther are tight or not.
4) Confirming the power and control switch according to clc brick making machine and its assistant
machine's power.
5) Check finished, we should have a empty load test first. If the test is ok, we can make normal production.
Work site of clc brick making machine show:
Part Eight: How to choose the most suitable clc brick making machine?
1) At first, I need to know your raw material.
2) Second, I need to know the brick size, shape.
3) Third, I need to know how many pieces your will make per hour or per day.
4) Fourth, what/s your bricks' application?(clc brick making machine)
Delivery site of clc brick making machine
Visitors came to our factory to test clc brick making machine
Our service:
Before-sale services:
(1) tell customer how to build new brick factory, including clc brick making machine, drying and firing.
(Confirm clay,power electricity,water,land area, fund)
(2) Guide customers to choose the best and economic plant, recover the investment within short time.
(3) site inspection.(clc brick making machine)
In-Sale services:
(1)Quality of clc brick making machine control must be inspected strictly
(2)In accordance with the agreements stipulated in the contract.(clc brick making machine)
After-sale services:
(1) We will send the technicians about clc brick making machine to guide with device installation, debugging
and training operators until customers are fully satisfied.
(2) Guarantee for clc brick making machine, materials and equipment supplied under this quotation are valid
for a period of 12 months after commissioning or 16 months after delivery whichever is earlier. Warranty shall
cover manufacturing defect in material and workmanship but exclude:1. Daily wear and tear 2.mishandling or
improper operation3. Incoming power supply fluctuation.(clc brick making machine)
