Antenna Manufactory 1200MHz(1.2GHz) 15dB Directional Yagi Antenna

Name: Antenna Manufactory 1200MHz(1.2GHz) 15dB Directional Yagi Antenna
Brand: AMEISON
SKU: 126223583
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-1200-15

Shenzhen Ameison Communication Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-1200-15

1200MHz Directional Yagi Antenna

AMXY-1200-15

Feature:

High gain

Aluminum alloy framework

Full day working

Optimized dimension

Mounting way can be Vertical or Horizontal

Application:

1.2GHz system

Point-to-point,point-to-multipoint system

Wireless bridging,client termination antenna

good appearance, anti-aging, easy to mount

AMXY-1200-15 Electrical Specifications
Frequency range(MHz)	1100-1300
Bandwidth(MHz)	200
Gain(dBi)	15
Element	13
Half-power beam width(°)	H:40 V:37
Front-to-back ratio(dB)	≥16
VSWR	≤2.0
Input Impedance(Ω)	50
Polarization	Horizontal or Vertical
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	N female or others
Mechanical Specifications
Dimensions(mm)	81013056
Cable length(m)	0.3
Antenna weight(kg)	0.45
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Clamp	U-shape
Mounting hardware(mm)	Φ35~Φ50
