Antenna manufactory 890-960MHz 12dB Directional dual polarization Yagi Antenna
AMXY-8090-12
Features:
High gain
Aluminum alloy framework
Full day working
Optimized dimension
Mounting way can be Vertical or Horizontal
Application:
CDMA, GSM system
Point-to-point, point-to-multipoint system
Client terminal antennas
|
AMXY-8090-12 Electrical Specifications | |
Frequency range(MHz) |
890-960 |
Bandwidth(MHz) |
70 |
Gain(dBi) |
12 |
Element |
11 |
Half-power beam width(°) |
H:36 V:34 |
Front-to-back ratio(dB) |
≥16 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Horizontal or Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
TNC Male or Requested |
Mechanical Specifications | |
Dimensions(mm) |
840*190*54 |
Cable length(m) |
0.3 |
Antenna weight(kg) |
0.4 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Clamp |
U-shape |
Mounting hardware(mm) |
Φ35~Φ50 |
After-sale service:
1)All of our product will have been strictly test before packing
2)All of our product will be well packed before shipping
3)All of our prodect will have one year quality warranty, free maintenance with warranty period!
OEM/ODM ORDERS ARE WELCOMED BY US.
