Antenna manufactory 824-960MHz 12dB Directional GSM Yagi Antenna
AMXY-8090-12
Feature:
High gain
Aluminum alloy framework
Full day working
Optimized dimension
Mounting way can be Vertical or Horizontal
Application:
CDMA,GSM system
Point-to-point,point-to-multipoint system
Wireless bridging,client termination antenna
|
AMXY-8090-12 Electrical Specifications | |
Frequency range(MHz) |
824-960 |
Bandwidth(MHz) |
136 |
Gain(dBi) |
12 |
Element |
8 |
Half-power beam width(°) |
H:48 V:40 |
Front-to-back ratio(dB) |
≥16 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Horizontal or Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N female or others |
Mechanical Specifications | |
Dimensions(mm) |
720*190*54 |
Cable length(m) |
0.3 |
Antenna weight(kg) |
0.4 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Clamp |
U-shape |
Mounting hardware(mm) |
Φ35~Φ50 |
Welcome to Ameison Communication Equipment Co.,Ltd, we are leading antenna manufacturer in China.
Ameison Antennas have been working in worldwide for over 6 tears. Our antennas cover GSM, CDMA, 3G, 4G, LTE, Wifi, Wimax, Wlan, UHF TV, VHF TV, RFID, Cluster, Marine and so on. Now we have a lots of MIMO and DAS models are hot selling.
provide you:
high quality products
better product pre-sales and after-sales service
attractive prices
shorter delivery
Long-term business cooperation is our ultimate goal, making high quality products and considerate service is our top priority.
your choice + our products > win-win situation
We are a manufacturer, NOT trading company.
Per our factory always tell our customers all along: you win, Ameison factory will win, we do win-win long-term business, NOT one-shot deal.
We welcome you to schedule a visit our factory anytime and consult with us for more business when you feel free.
