Specifications
wood crusher with CE-Fine sawdust from sawdust making machine
-Factory direct price
-Wood sawdust machine with thicker blade
2014 Hot Saled Widely Used Best SellingWood Sawdust Machine with CE and ISO Certifications and Sawdust Making Machine
Brief Introduction of 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications :
After many years hard working and testing, now we promoted a new type wood crusher. It is specialized in dealing with hard fruitwood, such as pearwood, applewood, peach wood, fruitwood branches and so on. Compared with the old one, it is different in the structure which can produce high quality raw material of edible mushroom.Now we have exported the sawdust making machine to Russia, Spain, Australia, Italy, New Zealand, Vietnam and so on.
Structure Features of 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications :
This new type sawdust making machine consists frame, shell, lining plate, spindle, blade, cutterhead, hammer, screen, draught fan, pulley, etc. It has features of small floor area, firm structure, low energy consumption, high efficiency, good shape finished product and suitable for flow work. Especially in the industry of process edible mushroom, it is the most perfect choice.
Working Principles of 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications :
The wood sawdust machine has 6 blades, but the old type only has 4 blades. Different on the structure, so the operating principle is also different. This new type takes charging through entrance, first the blades cut the raw materials into small pieces, then do the next crushing with hammer. The pulverized materials will be screened through screen. Because it is negative direction discharging, then a draught fan is installed on the spindle. This makes the wind at the exit and takes the crushing materials out. Then the whole crushing process of wood sawdust machine is complete.
Maintaining of 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications :
1.Because of long time wok, the bearings in the spindle need add butter. Works much longer, need add more butter. Or the bearings will be heated and then damaged which will influence the normal operation.
2.After long time work, the blades of sawdust making machine will get blunt. This time need disboard them and sharpen them with sharpener or stone by hand until them get sharped. If the blades are not sharp, this will influence capacity and also damage machine easily.
3.The V-belt needs to adjust degree of tightness after using a time. Press the middle of the belt with finger to fall 6-10mm.
4.Everyday when finished work, should clean the machine and check whether the machine is lose to increase service life.The lumber mill is kind of advances crusing griding equipment. On the basisi of crusher, being designed through the theory of cutting ,shocking, beating ,striking each other and griding. The wood sawdust machine can crushed the logs into sawdust-like which can be used as biomass fuels and papermaking.
Technical Data of 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications :
Type |
420 |
500 |
600 |
700 |
800 |
1000 |
Diameter of Cutterhead(mm) |
420 |
500 |
600 |
700 |
800 |
1000 |
Quantity of Blades |
4 |
4 |
4 |
4 |
6 |
4-6 |
Length of Blade(mm) |
90 |
100 |
150 |
200 |
230 |
260 |
Size of Feeding Port(mm) |
150×180 |
180×200 |
200×200 |
200×250 |
250×300 |
300×300 |
Speed of Main Shaft( r/min) |
2600 |
2600 |
2600 |
2300 |
2000 |
2000 |
Power(kw) |
11-15 |
15-18.5 |
18.5-22 |
22-30 |
37-45 |
75+7.5 |
Capacity(kg/h) |
300-600 |
500-800 |
600-1200 |
800-1800 |
1000-2500 |
1800-3000 |
Final Granule Size(mm) |
According to customers' needs, the granule can be adjusted by changing the screen mesh. |
|||||
Note: We do have other kind 2014 wood crusher with CE and Sawdust Making Machine and Wood Sawdust Machine with CE and ISO Certifications for your needs. Any questions about wod crusher, sawdust making machine and wood sawdust machine that I can help, please don't hesitate to contact me.
