2*2 1550nm SM quick coupler fused splitter
Features
Low Insertion Loss
Low PDL
High Reliability
Applications
Optical Communication System
Optical Test System
Fiber Sensor Systems
pecification
Parameters |
Unit |
P |
A |
|
Wavelength |
nm |
1310 or 1550 or C+L Band |
||
Band width |
nm |
±40 |
||
PDL |
dB |
≤0.10 |
≤0.15 |
|
|
Insertion Loss
|
50:50 |
dB |
≤3.7/3.7 |
≤3.9/3.9 |
|
30:70 |
|
≤2.2/6.0 |
≤2.4/6.5 |
|
20:80 |
|
≤1.5/8.2 |
≤1.7/8.7 |
|
10:90 |
|
≤1.0/11.5 |
≤1.15/12.2 |
|
5:95 |
|
≤0.8/14.8 |
≤0.9/15.5 |
|
2:98 |
|
≤0.4 /19 |
≤0.6 /19.5 |
|
1:99 |
|
≤0.25/22 |
≤0.5/23.5 |
Directivity |
dB |
≥55 |
||
Operating Temperature |
°C |
-40 ~ +85 |
||
Storage Temperature |
°C |
-40 ~ +85 |
||
Package |
mm |
Bare fiber |
Ø3X54 |
|
|
|
900um loose tube |
Ø3X60 |
|
|
|
2mm or 3mm Cable |
100X80X10 |
|
Fiber Type |
Corning SMF-28-E |
|||
Note: 1. The above specifications are without connector
2. Other specification can be made on customer request
Order information
WBC |
Wavelength |
Structure |
Grade |
Coupling Ratio |
Pigtail Type |
Fiber length |
Connector |
Package |
|
13=1310 15=1550 |
1=1X2 2=2X2 |
P A |
50=50:50 30=30:70 10=10: 90 01=1: 99
|
0=bare fiber 1=loose tube 2=2mm cable 3=3mm cable |
05=0.5m 10=1.0m 15=1.5m |
0=none 1=FC/PC 2=FC/APC 3=SC/PC
|
3x54 3x60 |
| |
|
|
|
|
|
|
